Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-VX777
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
< DIODE >
D971 8-719-911-19 DIODE 1SS133T-72
D972 8-719-024-99 DIODE 11ES2-NTA2B
D973 8-719-024-99 DIODE 11ES2-NTA2B
D974 8-719-024-99 DIODE 11ES2-NTA2B
D975 8-719-024-99 DIODE 11ES2-NTA2B
< IC >
IC971 8-759-158-62 IC TA78057S
< TRANSISTOR >
Q971 8-729-119-79 TRANSISTOR 2SC2785-FEK (E,EA,SP,IA)
< RELAY >
0RY971 1-755-276-11 RELAY, POWER
< SWITCH >
0S901 1-786-055-11 SELECTOR, VOLTAGE
< TRANSFORMER >
0T972 1-435-867-11 TRANSFORMER, POWER
**************************************************************
1-680-892-11 SWITCH BOARD
***********
< CAPACITOR >
C401 1-126-964-11 ELECT 10uF 20.00% 50V
C402 1-126-961-11 ELECT 2.2uF 20.00% 50V
C403 1-126-961-11 ELECT 2.2uF 20.00% 50V
C451 1-126-964-11 ELECT 10uF 20.00% 50V
C452 1-126-961-11 ELECT 2.2uF 20.00% 50V
C781 1-104-665-11 ELECT 100uF 20.00% 10V
C782 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C784 1-126-964-11 ELECT 10uF 20.00% 50V
C785 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C786 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C788 1-126-964-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
CN403 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE)5P
CN607 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE)4P
* CN781 1-564-518-11 PLUG, CONNECTOR 3P
< DIODE >
D781 8-719-988-61 DIODE 1SS355TE-17
D782 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC401 8-759-525-25 IC BU4052BCF-E2
IC781 8-759-295-90 IC NJM2244M-TE2
< JACK >
J401 1-774-227-11 JACK, PIN 1P
J402 1-770-612-12 JACK, PIN 2P
< TRANSISTOR >
Q401 8-729-113-13 TRANSISTOR FA1A4M-L33
< RESISTOR >
R401 1-216-845-11 METAL CHIP 100K 5% 1/16W
R402 1-216-845-11 METAL CHIP 100K 5% 1/16W
R403 1-216-845-11 METAL CHIP 100K 5% 1/16W
R404 1-216-821-11 METAL CHIP 1K 5% 1/16W
R405 1-216-845-11 METAL CHIP 100K 5% 1/16W
R451 1-216-845-11 METAL CHIP 100K 5% 1/16W
R452 1-216-845-11 METAL CHIP 100K 5% 1/16W
R453 1-216-845-11 METAL CHIP 100K 5% 1/16W
R454 1-216-821-11 METAL CHIP 1K 5% 1/16W
R455 1-216-845-11 METAL CHIP 100K 5% 1/16W
R481 1-216-833-11 METAL CHIP 10K 5% 1/16W
R782 1-216-845-11 METAL CHIP 100K 5% 1/16W
R783 1-218-285-11 RES-CHIP 75 5% 1/16W
**************************************************************
A-4725-689-A VIDEO BOARD, COMPLETE (E,EA,SP,IA)
*********************************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-164-670-11 CERAMIC CHIP 1200PF 5.00% 16V
C103 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-164-670-11 CERAMIC CHIP 1200PF 5.00% 16V
C203 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C304 1-164-388-91 CERAMIC CHIP 270PF 5.00% 50V
C305 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C306 1-164-388-91 CERAMIC CHIP 270PF 5.00% 50V
C307 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C308 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C309 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C310 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C311 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C312 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C313 1-164-816-11 CERAMIC CHIP 220PF 2.00% 50V
C314 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C315 1-164-217-11 CERAMIC CHIP 150PF 5.00% 50V
C316 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C317 1-126-193-11 ELECT 1uF 20% 50V
C318 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C319 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C320 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C321 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C322 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C323 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C324 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C325 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C401 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C402 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C504 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C505 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C506 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C507 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C508 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
