Menu List
151
Chapter 6 Menu Displays and Detailed Settings
12 MARKER 1 MARKER OFF/ON For details, see “Setting the
marker display” on page 199.
CENTER OFF/ON
CENTER MARK 1/2/3/4
SAFTY ZONE OFF/ON
SAFTY AREA 80%/90%/92.5%/95%
ASPECT OFF/ON
ASPECT SELECT 15:9/14:9/13:9/4:3/1.85/
2.35
ASPECT MASK OFF/ON
ASPECT MASK LVL 0 to 12 to 15
100% MARKER OFF/ON
13 MARKER 2 USER BOX OFF/ON
USER BOX WIDTH 3 to 240 to 479
USER BOX HEIGHT 3 to 135 to 269
USER BOX H POS –477 to 0 to 476
USER BOX V POS –267 to 0 to 266
CENTER H POS –480 to 0 to 479
CENTER V POS –270 to 0 to 269
ASPECT SAFE ZONE OFF/ON
ASPECT SAFE AREA 80%/90%/92.5%/95%
14 GAIN SW GAIN LOW –6dB/–3dB/0dB/3dB/
6dB/9dB/12dB/18dB/
24dB/30dB/36dB/42dB
For details, see “Setting gain
values for the GAIN selector
positions” on page 203.
GAIN MID –6dB/–3dB/0dB/3dB/
6dB/9dB/12dB/18dB/
24dB/30dB/36dB/42dB
GAIN HIGH –6dB/–3dB/0dB/3dB/
6dB/9dB/
12dB/18dB/
24dB/30dB/36dB/42dB
GAIN TURBO –6dB/–3dB/0dB/3dB/
6dB/9dB/12dB/18dB/
24dB/30dB/36dB/42dB
TURBO SW IND OFF/ON
SHOCKLESS GAIN OFF/ON
15 VF SETTING ZEBRA OFF/ON For details, see “Setting the
viewfinder” on page 200.
ZEBRA SELECT 1/2/BOTH
ZEBRA1 DET LVL 20% to 70% to 107%
ZEBRA1 APT LVL 1% to 10% to 20%
ZEBRA2 DET LVL 52% to 100% to 109%
VF DETAIL LEVEL (–99 to 99)
VF ASPECT (SD)
(When the REC
FORMAT item is set to
IMX50, IMX40,
IMX30, or DVCAM)
AUTO/16:9
No. Page Item Settings Description
