Menu List
155
Chapter 6 Menu Displays and Detailed Settings
25 SOURCE SEL FRONT MIC SELECT
(When stereo
microphone is
connected)
MONO/STREO Input mode selection for front
microphone.
REC VIDEO SOURCE
(When the CBK-HD01
or CBK-SC02 option
board is installed)
CAM/EXT For details, see “Recording video
from external devices” (page 95).
EXT VIDEO SOURCE
(When the CBK-HD01
or CBK-SC02 option
board is installed)
VBS/SDSDI/HDSDI
(VBS is displayed when
the CBK-SC02 is
installed. SDSDI and
HDSDI are displayed
when the CBK-HD01 is
installed.)
WIDE MODE(EXT)
(When the CBK-HD01
or CBK-SC02 option
board is installed)
AUTO/16:9 When the input signal is SD,
select the method that determines
whether the signal is treated as a
wide signal.
AUTO: When wide picture
information is detected in the
input signal, treat the signal
as a wide signal and set the
up-converter operating mode
to squeeze mode. Record
wide picture information
when recording SD. When
wide picture information is
not detected, set the up-
converter operating mode to
edge crop mode and do not
record wide picture
information.
16:9: Always treat the signal as a
wide signal and set the up-
converter operating mode to
squeeze mode. Record wide
picture information when
recording SD.
SETUP REMOVE
(When the COUNTRY
item is set to
“NTSC(J)AREA” or
“NTSC AREA” and the
CBK-SC02 option
board is installed)
0.0%/7.5% Selects whether to modify the
setup level of input video signals.
7.5%: Remove the setup. (Select
when signals with 7.5%
setup are input.)
0.0%: Do not remove the setup.
(Select when signals without
setup are input.)
26 UMID SET COUNTRY CODE Blank/up to 4 characters For details, see “Setting the
UMID data” on page 212.
ORGANIZATION Blank/up to 4 characters
USER CODE Blank/up to 4 characters
TIME ZONE 00 to 3F
No. Page Item Settings Description
To Next Page
