Sony STR-DA3300ES - Page 124

124
STR-DA3300ES/DG1100
Pin No. Pin Name I/O
Description
58
GND - Ground terminal
59
VDDEXT - Power supply terminal (+3.3V)
60
VDDINT - Power supply terminal (+1.2V)
61
GND - Ground terminal
62
PF_CE I/O Chip enable signal input/output terminal Not used
63 SPI_MAS O
Master/slave selection signal output to the system controller "L": DSP is master
64 DPSOA O
PCM audio signal (front L/R) output to the D/A converter
65 DPSOB O
PCM audio signal (surround L/R) output to the D/A converter
66
VDDINT - Power supply terminal (+1.2V)
67
GND - Ground terminal
68
VDDINT - Power supply terminal (+1.2V)
69
GND - Ground terminal
70 DPSOC O
PCM audio signal (center, sub woofer) output to the D/A converter
71 DPSOD O
PCM audio signal (surround back L/R) output to the D/A converter
72
VDDINT - Power supply terminal (+1.2V)
73
VDDEXT - Power supply terminal (+3.3V)
74
GND - Ground terminal
75
VDDINT - Power supply terminal (+1.2V)
76
GND - Ground terminal
77
DPSOE O PCM audio signal output terminal Not used
78 DPSIA I
PCM audio signal (digital input) input from the digital audio interface receiver
79 DPSIB I
PCM audio signal (front L/R) input from the A/D converter, HDMI receiver or XM receiver
80 DPSIC I
PCM audio signal (surround L/R) input from the HDMI receiver
81 DPSID I
PCM audio signal (center, sub woofer) input from the HDMI receiver
82 DPSIE I
PCM audio signal (surround back L/R) input from the HDMI receiver
83
VDDINT - Power supply terminal (+1.2V)
84, 85
GND - Ground terminal
86 DPDVLRCK O
L/R sampling clock signal output for PCM audio output to the D/A converter
87 DPDVBCK O
Bit clock signal output for PCM audio output to the D/A converter
88 DPLRCK I
L/R sampling clock signal input for PCM audio input from the digital audio interface receiver,
HDMI receiver or XM receiver
89 DPBCK I
Bit clock signal input for PCM audio input from the digital audio interface receiver, HDMI
receiver or XM receiver
90
VDDINT - Power supply terminal (+1.2V)
91, 92
GND - Ground terminal
93
VDDEXT - Power supply terminal (+3.3V)
94 DPFSCK I
Master clock signal input from the digital audio interface receiver, HDMI receiver or XM receiver
95
GND - Ground terminal
96
VDDINT - Power supply terminal (+1.2V)
97 XNONAUDIO I
PCM audio data input from the digital audio interface receiver
98
XSF_CE
O
Chip enable signal output to the serial flash
99
VDDINT - Power supply terminal (+1.2V)
100
GND - Ground terminal
101
VDDINT - Power supply terminal (+1.2V)
102
GND - Ground terminal
103
VDDINT - Power supply terminal (+1.2V)
104
GND - Ground terminal
105
VDDINT - Power supply terminal (+1.2V)
