Sony STR-DA3300ES - Page 125

125
STR-DA3300ES/DG1100
Pin No.
Pin Name I/O Description
106
GND - Ground terminal
107, 108
VDDINT - Power supply terminal (+1.2V)
109
GND - Ground terminal
110
VDDINT - Power supply terminal (+1.2V)
111
GND - Ground terminal
112
VDDINT - Power supply terminal (+1.2V)
113
GND - Ground terminal
114
VDDINT - Power supply terminal (+1.2V)
115
GND - Ground terminal
116
VDDEXT - Power supply terminal (+3.3V)
117
GND - Ground terminal
118
VDDINT - Power supply terminal (+1.2V)
119
GND - Ground terminal
120
VDDINT - Power supply terminal (+1.2V)
121
XRESET I Reset signal input from the system controller "L": reset
122
XSPIDS I Serial data latch pulse signal input from the system controller
123
GND - Ground terminal
124
VDDINT - Power supply terminal (+1.2V)
125
SPICLK O Serial data transfer clock signal output to the serial flash
126
MISO I Serial data input from the serial flash
127
MOSI O Serial data output to the serial flash
128
GND - Ground terminal
129
VDDINT - Power supply terminal (+1.2V)
130
VDDEXT - Power supply terminal (+3.3V)
131
AVDD - Power supply terminal (+3.3V)
132
AVSS - Ground terminal
133
GND - Ground terminal
134
CLKOUT - Not used
135
XEMU - Not used
136
TDO - Not used
137
TDI - Not used
138
CTRST - Not used
139
TCK - Not used
140
TMS - Not used
141
GND - Ground terminal
142
CLKIN I System clock input terminal (25 MHz)
143
XTAL O System clock output terminal (25 MHz)
144
VDDEXT - Power supply terminal (+3.3V)
