Sony STR-DA3300ES - Page 126

126
STR-DA3300ES/DG1100
D_VIDEO BOARD IC3503 TMDS341PFCR (HDMI INPUT SELECT)
Pin No.
Pin Name I/O Description
1
NC - Not used
2
SDA1 I/O I2C two-way data bus with the HDMI ASSIGNABLE (INPUT ONLY) IN 1 jack
3
SCL1 I I2C clock signal input from the HDMI ASSIGNABLE (INPUT ONLY) IN 1 jack
4
GND - Ground terminal
5
B11 I TMDS clock signal (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 1 jack
6
A11 I TMDS clock signal (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 1 jack
7
VCC - Power supply terminal (+3.3V)
8
B12 I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 1 jack
9
A12 I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 1 jack
10
GND - Ground terminal
11
B13 I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 1 jack
12
A13 I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 1 jack
13
VCC - Power supply terminal (+3.3V)
14
B14 I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 1 jack
15
A14 I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 1 jack
16
GND - Ground terminal
17
VCC - Power supply terminal (+3.3V)
18
VSADJ I TMDS compliant voltage swing control signal input terminal Not used
19
PRE I Output de-emphasis setting terminal "L": 0 dB, "H": 3 dB Fixed at "L" in this set
20
NC - Not used
21 to 23
S1 to S3 I Source selection signal input from the video system controller
24
GND - Ground terminal
25
Y4 O TMDS data (positive) output to the HDMI receiver
26
Z4 O TMDS data (negative) output to the HDMI receiver
27
VCC - Power supply terminal (+3.3V)
28
Y3 O TMDS data (positive) output to the HDMI receiver
29
Z3 O TMDS data (negative) output to the HDMI receiver
30
GND - Ground terminal
31
Y2 O TMDS data (positive) output to the HDMI receiver
32
Z2 O TMDS data (negative) output to the HDMI receiver
33
VCC - Power supply terminal (+3.3V)
34
Y1 O TMDS data (positive) output to the HDMI receiver
35
Z1 O TMDS data (negative) output to the HDMI receiver
36, 37
GND - Ground terminal
38
SCL_SINK O I2C clock signal output to the EEPROM and HDMI receiver
39
SDA_SINK I/O I2C two-way data bus with the EEPROM and HDMI receiver
40
HPD_SINK I Hot plug detection signal input from the video system controller
41
NC - Not used
42
xOE I Chip enable signal input from the video system controller
43
VCC - Power supply terminal (+3.3V)
44
HPD3 O Hot plug detection signal output to the HDMI ASSIGNABLE (INPUT ONLY) IN 3 jack
45
SDA3 I/O I2C two-way data bus with the HDMI ASSIGNABLE (INPUT ONLY) IN 3 jack
46
SCL3 I I2C clock signal input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 jack
47
GND - Ground terminal
48
B31 I TMDS clock signal (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 jack
49
A31 I TMDS clock signal (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 jack
