Sony STR-DA3300ES - Page 127

127
STR-DA3300ES/DG1100
Pin No.
Pin Name I/O Description
50
VCC - Power supply terminal (+3.3V)
51
B32 I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 jack
52
A32 I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 jack
53
GND - Ground terminal
54
B33 I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 jack
55
A33 I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 jack
56
VCC - Power supply terminal (+3.3V)
57
B34 I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 jack
58
A34 I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 3 jack
59
GND - Ground terminal
60
NC - Not used
61
VCC - Power supply terminal (+3.3V)
62
HPD3 O Hot plug detection signal output to the HDMI ASSIGNABLE (INPUT ONLY) IN 2 jack
63
SDA3 I/O I2C two-way data bus with the HDMI ASSIGNABLE (INPUT ONLY) IN 2 jack
64
SCL3 I I2C clock signal input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 jack
65
GND - Ground terminal
66
B31 I TMDS clock signal (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 jack
67
A31 I TMDS clock signal (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 jack
68
VCC - Power supply terminal (+3.3V)
69
B32 I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 jack
70
A32 I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 jack
71
GND - Ground terminal
72
B33 I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 jack
73
A33 I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 jack
74
VCC - Power supply terminal (+3.3V)
75
B34 I TMDS data (negative) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 jack
76
A34 I TMDS data (positive) input from the HDMI ASSIGNABLE (INPUT ONLY) IN 2 jack
77
GND - Ground terminal
78
NC - Not used
79
VCC - Power supply terminal (+3.3V)
80
HPD1 O Hot plug detection signal output to the HDMI ASSIGNABLE (INPUT ONLY) IN 1 jack
