128
STR-DA3300ES/DG1100
D_VIDEO BOARD IC3511 SII9011CLU (HDMI RECEIVER)
Pin No.
Pin Name I/O Description
1
VSYNC O Vertical sync signal output to the HDMI transmitter, video processor, video system controller
2 to 5
QO23 to QO20 - Not used
6
IOGND - Ground terminal
7
IOVCC - Power supply terminal (+3.3V)
8 to 11
QO19 to QO16 - Not used
12
CVCC18 - Power supply terminal (+1.8V)
13
CGND - Ground terminal
14 to 17
QO15 to QO12 - Not used
18
IOGND - Ground terminal
19
IOVCC - Power supply terminal (+3.3V)
20 to 23
QO11 to QO8 - Not used
24
CVCC18 - Power supply terminal (+1.8V)
25
CGND - Ground terminal
26 to 29
QO7 to QO4 - Not used
30
IOGND - Ground terminal
31
IOVCC - Power supply terminal (+3.3V)
32 to 35
QO3 to QO0 - Not used
36
CVCC18 - Power supply terminal (+1.8V)
37
CGND - Ground terminal
38
CI2CA - Not used
39
CSDA I/O
I2C two-way data bus with the EEPROM, HDMI transmitter, video system controller and D/A
converter
40
CSCL I I2C clock signal input from the video system controller
41
DSDA I/O I2C two-way data bus with the HDMI input select and EEPROM
42
DSCL I I2C clock signal input from the HDMI input select and EEPROM
43
NC - Not used
44
PWR5V I HDMI ASSIGNABLE (INPUT ONLY) IN jack detection signal input terminal
45
CVCC18 - Power supply terminal (+1.8V)
46
PGND - Ground terminal
47
PVCC - Power supply terminal (+3.3V)
48
RSVD - Not used
49
AVCC - Power supply terminal (+3.3V)
50
RXC- I TMDS clock signal input from the HDMI input select
51
RXC+ I TMDS clock signal input from the HDMI input select
52
AGND - Ground terminal
53
AVCC - Power supply terminal (+3.3V)
54
RX0- I TMDS data input from the HDMI input select
55
RX0+ I TMDS data input from the HDMI input select
56
AGND - Ground terminal
57
AVCC - Power supply terminal (+3.3V)
58
RX1- I TMDS data input from the HDMI input select
59
RX1+ I TMDS data input from the HDMI input select
60
AGND - Ground terminal
61
AVCC - Power supply terminal (+3.3V)
62
RX2- I TMDS data input from the HDMI input select
63
RX2+ I TMDS data input from the HDMI input select
