129
STR-DA3300ES/DG1100
Pin No.
Pin Name I/O Description
64
AGND - Ground terminal
65
DGND - Ground terminal
66
DVCC18 - Power supply terminal (+1.8V)
67
MUTE O Audio muting control signal output terminal
68
IOVCC - Power supply terminal (+3.3V)
69
IOGND - Ground terminal
70
SPDIF O S/PDIF signal output to the digital audio interface receiver and HDMI transmitter
71 to 74
SD3 to SD0 O Serial data output to the DSP and HDMI transmitter
75
WS O Word select signal output to the DSP and HDMI transmitter
76
SCK O Serial clock signal output to the DSP and HDMI transmitter
77
IOVCC - Power supply terminal (+3.3V)
78
IOGND - Ground terminal
79
MCLK O Audio master clock signal output to the DSP and HDMI transmitter
80
CGND - Ground terminal
81
CVCC18 - Power supply terminal (+1.8V)
82
AUDPVCC18 - Power supply terminal (+1.8V)
83
AUDPGND - Ground terminal
84
XTALOUT O System clock output terminal (28.322 MHz)
85
XTALIN I System clock input terminal (28.322 MHz)
86
XTALVCC - Power supply terminal (+3.3V)
87
REGVCC - Power supply terminal (+3.3V)
88
RSVDL - Not used
89
RESET I Reset signal input from the video system controller "L": reset
90
SCDT - Not used
91
INT O Interrupt signal output to the video system controller
92 to 96
QE23 to QE19 O Serial data output to the HDMI transmitter, video processor and D/A converter
97
IOGND - Ground terminal
98
IOVCC - Power supply terminal (+3.3V)
99 to 105
QE18 to QE12 O Serial data output to the HDMI transmitter, video processor and D/A converter
106
IOGND - Ground terminal
107
IOVCC - Power supply terminal (+3.3V)
108 to 111
QE11 to QE8 O Serial data output to the HDMI transmitter, video processor and D/A converter
112
CVCC18 - Power supply terminal (+1.8V)
113
CGND - Ground terminal
114 to 117
QE7 to QE4 O Serial data output to the HDMI transmitter and video processor
118
IOGND - Ground terminal
119
ODCK O Output data clock signal output to the HDMI transmitter, video processor and D/A converter
120
IOVCC - Power supply terminal (+3.3V)
121 to 124
QE3 to QE0 O Serial data output to the HDMI transmitter and video processor
125
CGND - Ground terminal
126
CVCC18 - Power supply terminal (+1.8V)
127
DE O Data enable signal output to the HDMI transmitter, video processor and D/A converter
128
HSYNC O Horizontal sync signal output to the HDMI transmitter, video processor and D/A converter
