Sony STR-DA3300ES - Page 131

131
STR-DA3300ES/DG1100
Pin No.
Pin Name I/O Description
B25
RPLL_DGND - Ground terminal
B26
XTAL O System clock output terminal (19.6 MHz)
C1 to C3
BDATA3 to
BDATA1
IDigital video signal (B) input from the OSD controller
C4
FSCKE O Clock enable signal output to the SD-RAM
C5
FSCLKN O Clock signal (negative) output to the SD-RAM
C6 to C8
FSADDR8 to
FSADDR6
OAddress signal output to the SD-RAM
C9 FSVREF O
Reference voltage output to the SD-RAM
C10 to
C18
FSADDR5,
FSADDR12,
FSADDR9,
FSADDR4,
FSADDR11,
FSADDR3 to
FSADDR0
OAddress signal output to the SD-RAM
C19 FSVREF O
Reference voltage output to the SD-RAM
C20, C21
FSBKSEL1,
FSBKSEL0
O
Bank select signal output to the SD-RAM
C22
FSCS1 O Chip select signal output terminal Not used
C23
FSWE O Write enable signal output to the SD-RAM
C24
FSRAS
O
Row address strobe signal output to the SD-RAM
C25
RPLL_1.8V - Power supply terminal (+1.8V)
C26
TCLK I System clock input terminal (19.6 MHz)
D1
BDATA6 I Digital video signal input terminal Not used
D2, D3
BDATA5,
BDATA4
IDigital video signal (B) input from the OSD controller
D4
DDR_2.5V - Power supply terminal (+2.5V)
D5
FSCLKP O Clock signal (positive) output to the SD-RAM
D6 to D8
DDR_2.5V - Power supply terminal (+2.5V)
D9
FSVREFVSS - Ground terminal
D10 to D15
DDR_2.5V - Power supply terminal (+2.5V)
D16
FSADDR10 O Address signal output to the SD-RAM
D17, D18
DDR_2.5V - Power supply terminal (+2.5V)
D19
FSVREFVSS - Ground terminal
D20
DDR_2.5V - Power supply terminal (+2.5V)
D21
FSCS0 O Chip select signal output to the SD-RAM
D22, D23
DDR_2.5V - Power supply terminal (+2.5V)
D24 FSCAS O
Column address strobe signal output to the SD-RAM
D25
NC - Not used
D26
RPLL_3.3V - Power supply terminal (+3.3V)
E1, E2
BDATA9,
BDATA8
IDigital video signal (G) input from the OSD controller
E3
BDATA7 I Digital video signal input terminal Not used
E4
IO_3.3V - Power supply terminal (+3.3V)
E23, E24
PD22, PD23 I/O
Serial data input from the HDMI receiver and serial data output to the HDMI transmitter and D/A
converter
E25
LVDS_GND - Ground terminal
E26
LVDS_3.3V - Power supply terminal (+3.3V)
