STR-DA3300ES/DG1100
Pin No.
Pin Name I/O Description
F1 to F3
BDATA12 to
BDATA10
IDigital video signal (G) input from the OSD controller
F4
IO_3.3V - Power supply terminal (+3.3V)
F23 to
F26
PD18 to PD21 I/O
Serial data input from the HDMI receiver and serial data output to the HDMI transmitter and D/A
converter
G1, G2
BDATA15,
BDATA14
IDigital video signal input terminal Not used
G3
BDATA13 I Digital video signal (G) input from the OSD controller
G4
IO_3.3V - Power supply terminal (+3.3V)
G23 to
G26
PD14 to PD17 I/O
Serial data input from the HDMI receiver and serial data output to the HDMI transmitter and D/A
converter
H1 to H3
BDATA18 to
BDATA16
IDigital video signal (R) input from the OSD controller
H4
IO_3.3V - Power supply terminal (+3.3V)
H23
LVDS_PLL_GND
-Ground terminal
H24
LVDS_PLL_3.3V
- Power supply terminal (+3.3V)
H25
LVDS_GND - Ground terminal
H26
LVDS_3.3V - Power supply terminal (+3.3V)
J1 to J3
BDATA21 to
BDATA19
IDigital video signal (R) input from the OSD controller
J4
IO_3.3V - Power supply terminal (+3.3V)
J23, J24
PD12, PD13 I/O
Serial data input from the HDMI receiver and serial data output to the HDMI transmitter and D/A
converter
J25
LVDS_GND - Ground terminal
J26
LVDS_3.3V - Power supply terminal (+3.3V)
K1
BHREF_DE I Blanking period signal input from the OSD controller
K2, K3
BDATA23,
BDATA22
IDigital video signal input terminal Not used
K4
IO_3.3V - Power supply terminal (+3.3V)
K10, K11
CORE_1.8V - Power supply terminal (+1.8V)
K12 to K15
D_GND - Ground terminal
K16, K17
CORE_1.8V - Power supply terminal (+1.8V)
K23 to
K26
PD8 to PD11 I/O
Serial data input from the HDMI receiver and serial data output to the HDMI transmitter and D/A
converter
L1
IPCLK3 I Clock signal input terminal Not used
L2
BVS I Vertical sync signal input from the OSD controller
L3
BHS I Horizontal sync signal input from the OSD controller
L4
IO_3.3V - Power supply terminal (+3.3V)
L10
D_GND - Ground terminal
L11
CORE_1.8V - Power supply terminal (+1.8V)
L12 to L15
D_GND - Ground terminal
L16
CORE_1.8V - Power supply terminal (+1.8V)
L17
D_GND - Ground terminal
L23 to L26
PD4 to PD7 I/O Serial data input from the HDMI receiver and serial data output to the HDMI transmitter
M1
DIP_CLEAN
_HS_OUT
OHorizontal sync signal output terminal Not used
M2
DIP_EXT
_CLAMP
-Not used
