STR-DA3300ES/DG1100
Pin No. Pin Name I/O Description
54
DSP_SPIDS O Serial data latch pulse signal output to the DSP
55
SF_CPU_CE O Chip enable signal output to the serial flash
56 SF_DSP_MAS I
Master/slave selection signal input from the DSP "H": DSP is master
57
VCC3 - Power supply terminal (+3.3V)
58
VSS - Ground terminal
59
D/A MUTE O Audio muting on/off control signal output terminal "H": muting on
60
TUNER_DATA O Serial data output to the tuner (FM/AM)
61
TUNER_CLK O Serial data transfer clock signal output to the tuner (FM/AM)
62 NO_USE -
Not used
63
DIR_DATA0 I Audio serial data input from the digital audio interface receiver
64
DIR_XMODE O Reset signal output to the digital audio interface receiver "L": reset
65
DIR_CE O Chip enable signal output to the digital audio interface receiver
66
DIR_DO I Serial data input from the digital audio interface receiver
67
DIR_RERR I PLL lock error signal and data error flag input from the digital audio interface receiver
68
DIR_CKST I Clock select signal input from the digital audio interface receiver
69
TUN_TUNED
I
Tuned detection signal input from the tuner (FM/AM)
70
TUN_LAT
O
Serial data latch pulse signal output to the tuner (FM/AM)
71
TUN_DO
I
Serial data input from the tuner (FM/AM)
72
RDS_DATA
I
RDS serial data input from the tuner (FM/AM) (DA3300ES: AEP, Russian, Ukrainian and UK
models only)
73
VCC3 - Power supply terminal (+3.3V)
74
VSS - Ground terminal
75
POW_RY O Relay drive signal (for main power) output terminal "H": relay on
76
PREOUT_RY O Relay drive signal (for pre out) output terminal "H": relay on
77
SIRIUS-POW_EN
O
Power enable signal output to the SIRIUS connector (DA3300ES: US and Canadian
models/DG1100 only)
78 NO_USE -
Not used
79
HP_RY O Relay drive signal (for headphone) output terminal "H": relay on
80 NO_USE -
Not used
81
SP-A_RY O Relay drive signal (for front A) output terminal "H": relay on
82
STOP
I
AC cut detection signal input terminal
83
SP-B_RY O Relay drive signal (for front B) output terminal "H": relay on
84
C_RY O Relay drive signal (for center) output terminal "H": relay on
85
SB_RY O Relay drive signal (for surround back) output terminal "H": relay on
86
SR_RY O Relay drive signal (for surround) output terminal "H": relay on
87
4/8_RY O Impedance 4/8 ohm selection signal output terminal
88
VSS - Ground terminal
89
VCC3 - Power supply terminal (+3.3V)
90 NO_USE -
Not used
91
FUNC_LAT O Serial data latch pulse signal output to the input selector (for analog audio)
92
EVOL_DAT O Serial data output to the electrical volume
93
AD_RST O Reset signal output to the A/D converter "L": reset
94
D/A_LAT O Serial data latch pulse signal output to the D/A converter
95
D/A_DO I Serial data input from the D/A converter
96
D/A_RST O Reset signal output to the D/A converter "L": reset
97
WDRESETX I Watch dog timer reset signal output terminal Not used
98 to100
AD-KEY1 to
AD-KEY3
I Front panel key input terminal (A/D input)
