STR-DA3300ES/DG1100
Pin No. Pin Name I/O Description
101, 102 NO_USE -
Not used
103
VERSION I Model and destination detection terminal
104 NO_USE -
Not used
105
2ND_RY O
Relay drive signal (for zone 2) output terminal "H": relay on (DA3300ES: US and Canadian
models only)
106
BRAVIA_SEL O PHONO IN/TV IN selection signal output terminal "L": PHONO IN, "H": TV IN
107
EVOL_CLK O Serial data transfer clock signal output to the electrical volume
108
D595_OE O Output enable signal output to the data decoder
109
D595_LAT O Serial data latch pulse signal output to the data decoder
110
COM1_CLK O
Serial data transfer clock signal output to the digital audio interface receiver, data decoder and D/A
converter
111
COM1_DATA O Serial data output to the digital audio interface receiver, data decoder and D/A converter
112
COM2_CLK O Serial data transfer clock signal output to the input selector (for analog audio) and data decoder
113
COM2_DATA O Serial data output to the input selector (for analog audio) and data decoder
114
AVSS/AVRL - Ground terminal
115
AVCC3 - Power supply terminal (+3.3V)
116
AVRH I Reference voltage input terminal (+3.3V)
117
IIC BUS DATA I/O I2C data bus terminal Not used
118
IIC BUS CLK I/O I2C clock bus terminal Not used
119
SIRCS-IN I SIRCS signal input terminal
120 NO_USE -
Not used
121
CEC_DV/M I CEC data input terminal
122 NO_USE -
Not used
123
ZONE_SEL I ZONE SELECT switch input terminal (DA3300ES: US and Canadian models only)
124
VIDEO-UCOM
_MODE
O Programming mode signal output to the video system controller
125
VIDEO-UCOM
_END-FLAG
O Programming end flag output to the video system controller
126
RST_TRG O Reset signal output terminal for the system controller "L": reset
127 MD3 -
Mode setting terminal Fixed at "L" in this set
128 MD2 I
Serial data input terminal
129, 130 MD1, MD0 -
Mode setting terminal Fixed at "L" in this set
131
INITX I
System reset signal input from the reset signal generator "L": reset
For several hundreds msec. after the power supply rises, "L" is input, then it changes to "H"
132
VSS - Ground terminal
133
VCC5 - Power supply terminal (+5V)
134
RS232C_MIN I Serial data input terminal
135
RS232C_MOUT O Serial data output terminal
136
VIDEO-UCOM
_RESET
O Reset signal output to the video system controller "L": reset
137
XM_XM/M I Serial data input from the XM receiver (DA3300ES: US and Canadian models/DG1100 only)
138
XM_M/XM O Serial data output to the XM receiver (DA3300ES: US and Canadian models/DG1100 only)
139
XM_RESET O
Reset signal output to the XM receiver "L": reset (DA3300ES: US and Canadian
models/DG1100 only)
140
VIDEO-UCOM
_VM/M
I Serial data input from the video system controller
141
VIDEO-UCOM
_M/VM
O Serial data output to the video system controller
