145
STR-DA3300ES/DG1100
Pin No. Pin Name I/O Description
142
VIDEO-UCOM
_BUSY
O Busy signal output to the video system controller
143
DSP_MISO I Serial data input from the serial flash
144
DSP_MOSI O Serial data output to the serial flash
145
DSP_CLK O Serial data transfer clock signal output to the serial flash
146
VSS - Ground terminal
147
VCC5 - Power supply terminal (+5V)
148
SIRIUS_TX I Serial data input from the SIRIUS connector (DA3300ES: US and Canadian models/DG1100 only)
149
SIRIUS_RX O Serial data output to the SIRIUS connector (DA3300ES: US and Canadian models/DG1100 only)
150
FL_CLR O Blanking period signal output to the fluorescent indicator tube
151
FL_LAT O Serial data latch pulse signal output to the fluorescent indicator tube
152
FL_DATA O Serial data output to the fluorescent indicator tube
153
FL_CLK O Serial data transfer clock signal output to the fluorescent indicator tube
154
DMUART_DM/M
I Serial data input from the DMPORT connector
155
DMUART_M/DM
O Serial data output to the DMPORT connector
156
DMPORT_DET I DMPORT detection signal input terminal
157, 158 NO_USE -
Not used
159 P15_2/O/T2 -
Not used
160 P15_3/O/T3 -
Not used
161
VSS - Ground terminal
162
VCC5 - Power supply terminal (+5V)
163
PROTECTOR I Protect signal input terminal
164 DSP_INT
I Interrupt request signal input from the DSP
165
RDS_CLK
I
RDS serial data transfer clock signal input from the tuner (FM/AM) (DA3300ES: AEP, Russian,
Ukrainian and UK models only)
166, 167
232C-SEL1,
232C-SEL2
O
Data selection signal output to the data selector
168
FSRATE1 I L/R sampling clock signal input terminal
169
LED-STB O LED drive signal output terminal for ON/STANDBY indicator "H": LED on
170 NO_USE -
Not used
171
LED-DCS O LED drive signal output terminal for Digital Cinema Sound indicator "H": LED on
172
LED-MLT O LED drive signal output terminal MULTI CHANNEL DECODING indicator "H": LED on
173
LED-MLT
-DIMMER
O
LED dimmer control signal output terminal for MULTI CHANNEL DECODING indicator
"H": dimmer on
174
EEPROM_SDA I/O Two-way data bus with the EEPROM
175
EEPROM_SCL O Serial data transfer clock signal output to the EEPROM
176
VCC5 - Power supply terminal (+5V)
Ver. 1.2
