STR-DA3300ES/DG1100
C_SPTM BOARD
*************
< CAPACITOR >
C1301 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< TERMINAL >
TB1301 1-780-405-11 TERMINAL BOARD (SP) (2P)
(CENTER SPEAKERS)
************************************************************
CIS BOARD (DA3300ES: US, CND)
*********
< CAPACITOR >
C801 1-126-947-11 ELECT 47uF 20% 35V
C802 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C803 1-126-961-11 ELECT 2.2uF 20% 50V
C804 1-126-947-11 ELECT 47uF 20% 35V
C805 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C807 1-164-388-91 CERAMIC CHIP 270PF 5% 50V
C821 1-126-960-11 ELECT 1uF 20% 50V
C851 1-126-767-11 ELECT 1000uF 20% 16V
C852 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C862 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C863 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C864 1-126-963-11 ELECT 4.7uF 20% 50V
C865 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C868 1-164-388-91 CERAMIC CHIP 270PF 5% 50V
C883 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C884 1-126-933-11 ELECT 100uF 20% 16V
C885 1-115-156-11 CERAMIC CHIP 1uF 10V
C886 1-115-156-11 CERAMIC CHIP 1uF 10V
C887 1-115-156-11 CERAMIC CHIP 1uF 10V
C888 1-115-156-11 CERAMIC CHIP 1uF 10V
< CONNECTOR >
CN801 1-779-279-11 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< DIODE >
D801 8-719-404-50 DIODE MA111-TX
D802 8-719-075-86 LED SID307BRTP19
(REMOTE CONTROL TRANSCEIVER)
D803 8-719-404-50 DIODE MA111-TX
D807 8-719-404-50 DIODE MA111-TX
D808 8-719-404-50 DIODE MA111-TX
< EARTH TERMINAL >
EB801 1-537-738-21 TERMINAL, GROUND
EB802 1-537-738-21 TERMINAL, GROUND
< FERRITE BEAD >
FB881 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC801 6-600-349-21 IC NJL23H400A
IC802 6-700-587-01 IC TC7W53F (TE12R)
IC861 8-759-470-63 IC NJM2145M-TE2
IC881 8-759-065-85 IC MAX232N
< JACK >
J801 1-563-330-31 JACK (IR REMOTE IN)
J802 1-563-330-31 JACK (IR REMOTE OUT1)
J803 1-563-330-31 JACK (IR REMOTE OUT2)
J821 1-563-330-31 JACK (TRIGGER OUT MAIN)
J861 1-563-330-31 JACK (CTRL S OUT)
J862 1-563-330-31 JACK (CTRL S IN)
J881 1-815-737-11 CONNECTOR, (D) SUB 9P (RS-232C)
< JUMPER RESISTOR >
JW861 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q821 8-729-037-13 TRANSISTOR KTA1271Y
Q822 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R801 1-216-833-11 METAL CHIP 10K 5% 1/10W
R802 1-216-797-11 METAL CHIP 10 5% 1/10W
R803 1-216-845-11 METAL CHIP 100K 5% 1/10W
R804 1-216-833-11 METAL CHIP 10K 5% 1/10W
R805 1-216-845-11 METAL CHIP 100K 5% 1/10W
R806 1-216-809-11 METAL CHIP 100 5% 1/10W
R807 1-216-809-11 METAL CHIP 100 5% 1/10W
R822 1-216-833-11 METAL CHIP 10K 5% 1/10W
R823 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R824 1-216-833-11 METAL CHIP 10K 5% 1/10W
R825 1-216-809-11 METAL CHIP 100 5% 1/10W
R861 1-216-821-11 METAL CHIP 1K 5% 1/10W
R862 1-216-821-11 METAL CHIP 1K 5% 1/10W
R863 1-216-821-11 METAL CHIP 1K 5% 1/10W
R864 1-216-821-11 METAL CHIP 1K 5% 1/10W
R865 1-216-821-11 METAL CHIP 1K 5% 1/10W
R881 1-216-809-11 METAL CHIP 100 5% 1/10W
R882 1-216-809-11 METAL CHIP 100 5% 1/10W
< THERMISTOR >
TH821 1-801-726-11 THERMISTOR, POSITIVE
************************************************************
CONNECTOR 3 BOARD
******************
< CONNECTOR >
CN1202 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
CN1203 1-784-041-41 CONNECTOR, BOARD TO BOARD 9P
************************************************************
CONNECTOR 4 BOARD
******************
< CONNECTOR >
CN1204 1-764-865-41 CONNECTOR, BOARD TO BOARD 13P
CN1207 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
************************************************************
C_SPTM CONNECTOR 3 CONNECTOR 4CIS
