Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
162
STR-DA3300ES/DG1100
A-1254-389-A CONTROL BOARD, COMPLETE
(DA3300ES: US, CND)
A-1254-408-A CONTROL BOARD, COMPLETE
(DA3300ES: AEP, ECE, UK)
A-1254-658-A CONTROL BOARD, COMPLETE (DG1100)
*************************
< CAPACITOR >
C2001 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2002 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2004 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2005 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2006 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2007 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2008 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2009 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2010 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2011 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2012 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2014 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2015 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2016 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2017 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2020 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2021 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2022 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2023 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2024 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2025 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2027 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2029 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2030 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2031 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2032 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2033 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND)
C2034 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2035 1-117-720-11 CERAMIC CHIP 4.7uF 10V
(DA3300ES: US, CND)
C2036 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2037 1-126-209-11 ELECT CHIP 100uF 20% 4V
C2038 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2039 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2040 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2041 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2042 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2043 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2044 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2045 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2046 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2047 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2048 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2049 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2050 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2051 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2052 1-126-193-11 ELECT CHIP 1uF 20% 50V
C2053 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2054 1-124-779-00 ELECT CHIP 10uF 20% 16V
C2055 1-126-209-11 ELECT CHIP 100uF 20% 4V
C2056 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2057 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2058 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C2059 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2060 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2061 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2062 1-126-208-21 ELECT CHIP 47uF 20% 4V
C2063 1-126-209-11 ELECT CHIP 100uF 20% 4V
C2065 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2066 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C2067 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C2068 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
< CONNECTOR >
CN2001 1-770-384-21 CONNECTOR, BOARD TO BOARD 16P
CN2002 1-770-382-11 CONNECTOR, BOARD TO BOARD 12P
(DA3300ES: US, CND/DG1100)
CN2003 1-770-381-11 CONNECTOR, BOARD TO BOARD 10P
CN2004 1-784-370-51 CONNECTOR, FFC/FPC 11P
(DA3300ES: US, CND)
CN2005 1-770-382-11 CONNECTOR, BOARD TO BOARD 12P
CN2006 1-770-382-11 CONNECTOR, BOARD TO BOARD 12P
CN2007 1-770-383-11 CONNECTOR, BOARD TO BOARD 14P
CN2008 1-770-405-11 CONNECTOR, BOARD TO BOARD 8P
CN2009 1-770-410-11 CONNECTOR, BOARD TO BOARD 18P
CN2010 1-770-410-11 CONNECTOR, BOARD TO BOARD 18P
CN2012 1-778-692-51 CONNECTOR, FFC/FPC 21P
* CN2013 1-785-125-21 CONNECTOR 6P
CN2014 1-778-692-51 CONNECTOR, FFC/FPC 21P
CN2015 1-784-930-11 PIN, CONNECTOR 15P
CN2016 1-784-926-11 PIN, CONNECTOR 11P
CN2017 1-784-928-11 PIN, CONNECTOR 13P
CN2020 1-764-177-11 PIN, CONNECTOR (SMD) (1.5mm) 7P
< DIODE >
D2001 8-719-060-48 DIODE RB751V-40TE-17
D2002 8-719-988-61 DIODE 1SS355TE-17
D2003 8-719-988-61 DIODE 1SS355TE-17
D2004 8-719-988-61 DIODE 1SS355TE-17
D2005 8-719-988-61 DIODE 1SS355TE-17
D2006 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB2001 1-469-152-11 FERRITE, EMI (SMD) (2012)
(DA3300ES: US, CND)
FB2002 1-469-152-11 FERRITE, EMI (SMD) (2012)
(DA3300ES: US, CND)
FB2003 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB2004 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB2005 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB2006 1-469-152-11 FERRITE, EMI (SMD) (2012)
CONTROL
Ver. 1.2
