STR-DA3300ES/DG1100
R1835 1-249-439-11 CARBON 68K 5% 1/4W
R1836 1-247-887-00 CARBON 220K 5% 1/4W
R1875 1-247-847-91 CARBON 4.7K 5% 1/4W
0R1876 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1877 1-249-420-11 CARBON 1.8K 5% 1/4W
R1878 1-249-431-11 CARBON 15K 5% 1/4W
R1879 1-247-862-11 CARBON 20K 5% 1/4W
R1880 1-249-419-11 CARBON 1.5K 5% 1/4W
R1881 1-247-871-91 CARBON 47K 5% 1/4W
R1882 1-249-431-11 CARBON 15K 5% 1/4W
R1883 1-247-871-91 CARBON 47K 5% 1/4W
R1884 1-247-863-91 CARBON 22K 5% 1/4W
R1885 1-249-439-11 CARBON 68K 5% 1/4W
R1886 1-247-887-00 CARBON 220K 5% 1/4W
************************************************************
A-1252-368-A PROTECTOR (SURR) BOARD, COMPLETE
*********************************
< CAPACITOR >
C1722 1-128-813-11 CERAMIC 220PF 5% 50V
C1723 1-136-153-00 MYLAR 0.01uF 5% 50V
C1724 1-126-964-11 ELECT 10uF 20% 50V
C1772 1-128-813-11 CERAMIC 220PF 5% 50V
C1773 1-136-153-00 MYLAR 0.01uF 5% 50V
C1774 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN1701 1-573-828-11 CONNECTOR, BOARD TO BOARD 14P
CN1704 1-573-846-11 CONNECTOR, BOARD TO BOARD 14P
* CN1761 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< DIODE >
D1721 8-719-991-33 DIODE 1SS133T-77
D1722 8-719-991-33 DIODE 1SS133T-77
D1771 8-719-991-33 DIODE 1SS133T-77
D1772 8-719-991-33 DIODE 1SS133T-77
< TRANSISTOR >
Q1722 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1723 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1724 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1772 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1773 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q1774 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R1725 1-247-847-91 CARBON 4.7K 5% 1/4W
0R1726 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1727 1-249-420-11 CARBON 1.8K 5% 1/4W
R1728 1-249-431-11 CARBON 15K 5% 1/4W
R1729 1-247-862-11 CARBON 20K 5% 1/4W
R1730 1-249-419-11 CARBON 1.5K 5% 1/4W
R1731 1-247-871-91 CARBON 47K 5% 1/4W
R1732 1-249-431-11 CARBON 15K 5% 1/4W
R1733 1-247-871-91 CARBON 47K 5% 1/4W
R1734 1-247-863-91 CARBON 22K 5% 1/4W
R1735 1-249-439-11 CARBON 68K 5% 1/4W
R1736 1-247-887-00 CARBON 220K 5% 1/4W
R1775 1-247-847-91 CARBON 4.7K 5% 1/4W
0R1776 1-240-855-91 CARBON 6.2K 5% 1/4W F
R1777 1-249-420-11 CARBON 1.8K 5% 1/4W
R1778 1-249-431-11 CARBON 15K 5% 1/4W
R1779 1-247-862-11 CARBON 20K 5% 1/4W
R1780 1-249-419-11 CARBON 1.5K 5% 1/4W
R1781 1-247-871-91 CARBON 47K 5% 1/4W
R1782 1-249-431-11 CARBON 15K 5% 1/4W
R1783 1-247-871-91 CARBON 47K 5% 1/4W
R1784 1-247-863-91 CARBON 22K 5% 1/4W
R1785 1-249-439-11 CARBON 68K 5% 1/4W
R1786 1-247-887-00 CARBON 220K 5% 1/4W
************************************************************
S_SPTM BOARD
*************
< CAPACITOR >
C4001 1-137-395-91 MYLAR 0.022uF 5% 100V
C4002 1-137-395-91 MYLAR 0.022uF 5% 100V
C4003 1-137-395-91 MYLAR 0.022uF 5% 100V
C4004 1-137-395-91 MYLAR 0.022uF 5% 100V
C4005 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4006 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4007 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4008 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4009 1-131-992-91 CERAMIC CHIP 100000PF 35V
C4010 1-131-992-91 CERAMIC CHIP 100000PF 35V
< CONNECTOR >
CN4001 1-784-921-11 PIN, CONNECTOR 4P
CN4002 1-785-105-11 PIN, CONNECTOR (3.96mm PITCH) 7P
CN4003 1-785-101-11 PIN, CONNECTOR (3.96mm PITCH) 3P
CN4004 1-785-104-11 PIN, CONNECTOR (3.96mm PITCH) 6P
< DIODE >
D4001 8-719-988-61 DIODE 1SS355TE-17
D4002 8-719-988-61 DIODE 1SS355TE-17
< TRANSISTOR >
Q4001 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q4002 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
0R4001 1-249-393-11 CARBON 10 5% 1/4W F
0R4002 1-249-393-11 CARBON 10 5% 1/4W F
0R4003 1-249-393-11 CARBON 10 5% 1/4W F
0R4004 1-249-393-11 CARBON 10 5% 1/4W F
0R4005 1-249-393-11 CARBON 10 5% 1/4W F
0R4006 1-249-393-11 CARBON 10 5% 1/4W F
R4007 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R4008 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4009 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R4010 1-216-833-11 METAL CHIP 10K 5% 1/10W
< RELAY >
RY4001 1-515-920-11 RELAY (24V)
PROTECTOR (SB) PROTECTOR (SURR)
