Sony STR-DA3300ES - Page 187

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
187
STR-DA3300ES/DG1100
RY4002 1-515-920-11 RELAY (24V)
< TERMINAL >
TB4001 1-780-404-11 TERMINAL BOARD (SP) (8P)
(SURROUND/SURROUND BACK SPEAKERS)
************************************************************
SUB WOOFER BOARD (DG1100)
******************
< CAPACITOR >
C4081 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C4082 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4083 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
< CONNECTOR >
CN4081 1-779-273-11 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
< DIODE >
D4081 8-719-988-61 DIODE 1SS355TE-17
D4082 8-719-988-61 DIODE 1SS355TE-17
D4083 8-719-988-61 DIODE 1SS355TE-17
< JACK >
J4081 1-774-785-11 JACK, PIN 1P (PRE OUT SUB WOOFER)
< TRANSISTOR >
Q4081 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R4081 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4082 1-216-833-11 METAL CHIP 10K 5% 1/10W
0R4083 1-249-393-11 CARBON 10 5% 1/4W F
R4084 1-216-821-11 METAL CHIP 1K 5% 1/10W
< RELAY >
RY4081 1-755-486-11 RELAY
************************************************************
TEMPERATURE DETECTION BOARD
*****************************
< CAPACITOR >
C1909 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1910 1-135-800-11 CERAMIC 1uF 50V
C1913 1-135-800-11 CERAMIC 1uF 50V
< DIODE >
D1906 8-719-109-93 DIODE RD6.2ESB2
< IC >
IC1903 6-710-072-01 IC LM61CIZ/LFT2
IC1905 6-710-072-01 IC LM61CIZ/LFT2
< RESISTOR >
R1928 1-249-414-11 CARBON 560 5% 1/4W
************************************************************
A-1252-458-A TUNER BOARD, COMPLETE
(DA3300ES: AEP, UK)
A-1254-402-A TUNER BOARD, COMPLETE
(DA3300ES: US, CND/DG1100)
**********************
< CAPACITOR >
C8001 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C8002 1-124-779-00 ELECT CHIP 10uF 20% 16V
(DA3300ES: US, CND/DG1100)
C8003 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(DA3300ES: US, CND/DG1100)
C8004 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(DA3300ES: US, CND/DG1100)
C8005 1-126-193-11 ELECT CHIP 1uF 20% 50V
C8006 1-126-193-11 ELECT CHIP 1uF 20% 50V
C8007 1-126-193-11 ELECT CHIP 1uF 20% 50V
C8008 1-126-193-11 ELECT CHIP 1uF 20% 50V
C8009 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(DA3300ES: US, CND/DG1100)
C8010 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8011 1-164-733-11 CERAMIC CHIP 820PF 10% 50V
(DA3300ES: US, CND/DG1100)
C8012 1-164-733-11 CERAMIC CHIP 820PF 10% 50V
(DA3300ES: US, CND/DG1100)
C8013 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
(DA3300ES: US, CND/DG1100)
C8014 1-128-994-21 ELECT CHIP 47uF 20% 10V
C8015 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C8016 1-126-208-21 ELECT CHIP 47uF 20% 4V
(DA3300ES: US, CND/DG1100)
C8017 1-126-208-21 ELECT CHIP 47uF 20% 4V
(DA3300ES: US, CND/DG1100)
C8018 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C8019 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C8020 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C8021 1-128-994-21 ELECT CHIP 47uF 20% 10V
C8023 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8024 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8027 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8029 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8030 1-128-994-21 ELECT CHIP 47uF 20% 10V
C8031 1-128-994-21 ELECT CHIP 47uF 20% 10V
C8032 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
(DA3300ES: US, CND/DG1100)
C8033 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
(DA3300ES: US, CND/DG1100)
C8034 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8036 1-128-994-21 ELECT CHIP 47uF 20% 10V
(DA3300ES: US, CND/DG1100)
C8037 1-128-994-21 ELECT CHIP 47uF 20% 10V
(DA3300ES: US, CND/DG1100)
SUB WOOFER TEMPERATURE DETECTION TUNERS_SPTM
Ver. 1.1
