Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
188
STR-DA3300ES/DG1100
C8038 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
(DA3300ES: US, CND/DG1100)
C8039 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8040 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8041 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
(DA3300ES: US, CND/DG1100)
C8042 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8043 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8044 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8045 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8046 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
(DA3300ES: US, CND/DG1100)
C8047 1-126-208-21 ELECT CHIP 47uF 20% 4V
C8048 1-126-208-21 ELECT CHIP 47uF 20% 4V
C8049 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
(DA3300ES: US, CND/DG1100)
C8050 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8051 1-126-209-11 ELECT CHIP 100uF 20% 4V
(DA3300ES: US, CND/DG1100)
C8052 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8053 1-117-681-11 ELECT CHIP 100uF 20% 16V
C8056 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8057 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8058 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
C8059 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
C8060 1-128-994-21 ELECT CHIP 47uF 20% 10V
C8061 1-128-994-21 ELECT CHIP 47uF 20% 10V
C8062 1-128-993-21 ELECT CHIP 22uF 20% 10V
(DA3300ES: US, CND/DG1100)
C8063 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8064 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8065 1-126-204-11 ELECT CHIP 47uF 20% 16V
(DA3300ES: US, CND/DG1100)
C8066 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8067 1-128-994-21 ELECT CHIP 47uF 20% 10V
(DA3300ES: US, CND/DG1100)
C8068 1-124-779-00 ELECT CHIP 10uF 20% 16V
(DA3300ES: US, CND/DG1100)
C8070 1-124-779-00 ELECT CHIP 10uF 20% 16V
(DA3300ES: US, CND/DG1100)
C8071 1-124-779-00 ELECT CHIP 10uF 20% 16V
(DA3300ES: US, CND/DG1100)
C8072 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(DA3300ES: US, CND/DG1100)
C8073 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
(DA3300ES: US, CND/DG1100)
C8074 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8075 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8076 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
(DA3300ES: US, CND/DG1100)
C8077 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
(DA3300ES: US, CND/DG1100)
C8078 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8079 1-124-779-00 ELECT CHIP 10uF 20% 16V
(DA3300ES: US, CND/DG1100)
C8080 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DA3300ES: US, CND/DG1100)
C8081 1-124-779-00 ELECT CHIP 10uF 20% 16V
(DA3300ES: US, CND/DG1100)
C8082 1-128-994-21 ELECT CHIP 47uF 20% 10V
C8083 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8084 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C8085 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C8086 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8087 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C8088 1-128-994-21 ELECT CHIP 47uF 20% 10V
C8090 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C8092 1-126-204-11 ELECT CHIP 47uF 20% 16V
C8093 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(DA3300ES: US, CND/DG1100)
C8094 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(DA3300ES: US, CND/DG1100)
C8095 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(DA3300ES: US, CND/DG1100)
C8096 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(DA3300ES: US, CND/DG1100)
< CONNECTOR >
CN8001 1-793-642-21 CONNECTOR (USB) (4P), SQUARE (XM)
(DA3300ES: US, CND/DG1100)
CN8002 1-821-182-11 SOCKET, DIN 8P (SIRIUS)
CN8003 1-817-615-21 CONNECTOR BOARD TO BOARD 18P
CN8004 1-568-830-11 CONNECTOR, FFC 11P (DA3300ES: AEP, UK)
CN8005 1-568-828-11 CONNECTOR, FFC 9P
(DA3300ES: US, CND/DG1100)
CN8006 1-770-409-11 CONNECTOR, BOARD TO BOARD 16P
CN8007 1-770-407-11 CONNECTOR, BOARD TO BOARD 12P
(DA3300ES: US, CND/DG1100)
CN8008 1-770-408-11 CONNECTOR, BOARD TO BOARD 14P
< DIODE >
D8001 8-719-988-61 DIODE 1SS355TE-17
D8002 8-719-988-61 DIODE 1SS355TE-17
D8003 8-719-083-02 DIODE KDS160-RTK
D8004 8-719-083-02 DIODE KDS160-RTK
D8005 6-500-462-01 DIODE NSAD500F-T1B
(DA3300ES: US, CND/DG1100)
D8006 8-719-988-61 DIODE 1SS355TE-17
< EARTH TERMINAL >
ET8001 1-780-318-11 TERMINAL
ET8002 1-780-318-11 TERMINAL
< FERRITE BEAD >
FB8001 1-469-152-11 FERRITE, EMI (SMD) (2012)
(DA3300ES: US, CND/DG1100)
TUNER
Ver. 1.1
