Sony STR-DA5000ES - 2 General; Location of Controls

10
STR-DA5000ES
SECTION 2
GENERAL
This section is extracted from
instruction manual.
LOCATION OF CONTROLS
– Front Panel –
Main unit
A.F.D. 6
BASS es
DECODE PRIORITY wd
Digital Cinema Sound indicator
4
Input indicators qd
DIRECT wf
DIRECT indicator 2
DISPLAY ws
Display 3
FM/AM ql
INPUT MODE qa
INPUT SELECTOR 0
IR receptor qf
MAIN MENU e;
MASTER VOLUME 9
MEMORY/ENTER w;
MENU wl
MOVIE 7
MULTI CH IN 1/2 wg
MULTI CHANNEL DECODING
indicator qs
MUSIC 8
PHONES jack qg
PRESET TUNING –/+ qj
SPEAKERS switch qh
SURR BACK DECODING wh
TREBLE ea
TUNING –/+ qk
USER PRESET wa
VIDEO 3 INPUT jacks wj
2CH 5
?/1 (power) 1
–/+ wk
ALPHABETICAL ORDER
NUMBERS AND SYMBOLS
v
1 2 3 4 65 7 8
qsqf 0qa
9
qd
wf wg wh
wj
wk
qkqjqhqg ql w; wa ws wd
ea e; wles
