Sony STR-DA5000ES - 3 Disassembly; Disassembly Flow; Case

11
STR-DA5000ES
1 two flat head screws
2
2
1 two flat head screws
1 two flat head screws
3 case
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
3-2. CASE
SET
3-2. CASE
(Page 11)
3-4. D-AMP BOARD
(Page 13)
3-3. FRONT PANEL SECTION
(Page 12)
