Sony STR-DA5000ES - 8 Electrical Parts List

119
STR-DA5000ES
SECTION 8
ELECTRICAL PARTS LIST
ANALOG SUB
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
•Abbreviation
CH : Chinese model
CND: Canadian model
TW : Taiwan model
A-4749-877-A ANALOG SUB BOARD, COMPLETE (US, CND)
A-4749-881-A ANALOG SUB BOARD, COMPLETE
(EXCEPT US, CND)
****************************
< CAPACITOR >
C111 1-137-431-11 MYLAR 560PF 5% 50V
C113 1-119-825-11 ELECT 22uF 20% 50V
(EXCEPT US, CND)
C113 1-128-858-11 ELECT 22uF 20% 50V
(US, CND)
C114 1-135-835-91 ELECT 1000uF 16V
C115 1-135-835-91 ELECT 1000uF 16V
C116 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C117 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C141 1-137-431-11 MYLAR 560PF 5% 50V
C143 1-119-825-11 ELECT 22uF 20% 50V
(EXCEPT US, CND)
C143 1-128-858-11 ELECT 22uF 20% 50V
(US, CND)
C147 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C148 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C161 1-137-431-11 MYLAR 560PF 5% 50V
C163 1-119-825-11 ELECT 22uF 20% 50V
(EXCEPT US, CND)
C163 1-128-858-11 ELECT 22uF 20% 50V
(US, CND)
C167 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C168 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C181 1-137-431-11 MYLAR 560PF 5% 50V
C183 1-119-825-11 ELECT 22uF 20% 50V
(EXCEPT US, CND)
C183 1-128-858-11 ELECT 22uF 20% 50V
(US, CND)
C187 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C188 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C211 1-137-431-11 MYLAR 560PF 5% 50V
C213 1-119-825-11 ELECT 22uF 20% 50V
(EXCEPT US, CND)
C213 1-128-858-11 ELECT 22uF 20% 50V
(US, CND)
C216 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C217 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C241 1-137-431-11 MYLAR 560PF 5% 50V
C243 1-119-825-11 ELECT 22uF 20% 50V
(EXCEPT US, CND)
C243 1-128-858-11 ELECT 22uF 20% 50V
(US, CND)
C247 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C248 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C261 1-137-431-11 MYLAR 560PF 5% 50V
C263 1-119-825-11 ELECT 22uF 20% 50V
(EXCEPT US, CND)
C263 1-128-858-11 ELECT 22uF 20% 50V
(US, CND)
C267 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C268 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C281 1-137-431-11 MYLAR 560PF 5% 50V
C283 1-119-825-11 ELECT 22uF 20% 50V
(EXCEPT US, CND)
C283 1-128-858-11 ELECT 22uF 20% 50V
(US, CND)
C287 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C288 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CNP601 1-784-927-11 PIN, CONNECTOR 12P
CNP602 1-784-928-11 PIN, CONNECTOR 13P
CNP620 1-784-041-41 CONNECTOR, BOARD TO BOARD 9P
CNP621 1-766-724-11 CONNECTOR, BOARD TO BOARD 7P
CNP622 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
< IC >
IC111 8-759-832-29 IC NJM4580M-(TE2)
IC141 8-759-832-29 IC NJM4580M-(TE2)
IC161 8-759-832-29 IC NJM4580M-(TE2)
IC181 8-759-832-29 IC NJM4580M-(TE2)
IC211 8-759-832-29 IC NJM4580M-(TE2)
IC241 8-759-832-29 IC NJM4580M-(TE2)
IC261 8-759-832-29 IC NJM4580M-(TE2)
IC281 8-759-832-29 IC NJM4580M-(TE2)
< RESISTOR >
R111 1-216-619-11 METAL CHIP 47 0.5% 1/10W
R112 1-216-675-11 METAL CHIP 1K 0.5% 1/10W
R113 1-216-675-11 METAL CHIP 1K 0.5% 1/10W
R114 1-216-619-11 METAL CHIP 47 0.5% 1/10W
R115 1-216-670-11 METAL CHIP 6.2K 0.5% 1/10W
R116 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R119 1-216-675-11 METAL CHIP 1K 0.5% 1/10W
When indicating parts by reference
number, please include the board.
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
