Sony STR-DA5000ES - Page 124

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
124
STR-DA5000ES
AUDIO
IC620 8-759-832-29 IC NJM4580M-(TE2)
IC621 8-759-832-29 IC NJM4580M-(TE2)
IC641 8-759-832-29 IC NJM4580M-(TE2) (US, CND)
IC642 6-702-387-01 IC CXD9725M (US, CND)
IC643 8-759-832-29 IC NJM4580M-(TE2) (US, CND)
IC651 8-759-832-29 IC NJM4580M-(TE2) (US, CND)
IC652 6-702-387-01 IC CXD9725M (US, CND)
IC653 8-759-832-29 IC NJM4580M-(TE2) (US, CND)
IC691 8-759-231-53 IC TA7805S
IC692 8-759-238-47 IC TC74HCT7007AF (EL)
< JACK >
J601 1-784-934-11 JACK, PIN 4P (MULTI CHANNEL INPUT 2
FRONT/SURROUND)
J602 1-817-602-11 JACK, PIN 2P (MULTI CHANNEL INPUT 2
SURR BACK)
J603 1-785-795-11 JACK, PIN 2P (MULTI CHANNEL INPUT 2
CENTER/SUB WOOFER)
J604 1-779-599-21 JACK, PIN 6P (MULTI CHANNEL INPUT 1
FRONT/SURROUND/CENTER/SUB WOOFER)
J605 1-778-517-11 JACK, PIN 6P (PHONO IN, CD/DVD IN,
MD DAT OUT)
J606 1-778-517-11 JACK, PIN 6P
(MD/DAT IN, TAPE OUT, TAPE IN)
J607 1-778-517-11 JACK, PIN 6P (TV/SAT AUDIO IN,
DVD AUDIO IN, VIDEO2 AUDIO OUT)
J608 1-778-517-11 JACK, PIN 6P (VIDEO2 AUDIO IN,
VIDEO1 AUDIO IN, VIDEO1 AUDIO OUT)
J609 1-784-934-11 JACK, PIN 4P (2ND/3RD ZONE OUT
AUDIO VARIABLE) (US, CND)
< TRANSISTOR >
Q631 8-729-230-49 TRANSISTOR 2SC2712-YG (US, CND)
Q632 8-729-027-24 TRANSISTOR DTA114TKA-T146 (US, CND)
Q641 8-729-230-49 TRANSISTOR 2SC2712-YG (US, CND)
Q651 8-729-230-49 TRANSISTOR 2SC2712-YG (US, CND)
Q661 8-729-230-49 TRANSISTOR 2SC2712-YG (US, CND)
Q662 8-729-027-24 TRANSISTOR DTA114TKA-T146 (US, CND)
< RESISTOR >
R117 1-216-238-00 RES-CHIP 47K 2% 1/8W
(US, CND)
R117 1-260-016-11 CARBON MELF 47K 2% 1/8W
(EXCEPT US, CND)
R121 1-216-222-00 RES-CHIP 1K 2% 1/8W
(US, CND)
R121 1-260-008-11 CARBON MELF 1K 2% 1/8W
(EXCEPT US, CND)
R122 1-208-561-11 RES-CHIP 27K 2% 1/8W
(US, CND)
R122 1-260-013-11 CARBON MELF 27K 2% 1/8W
(EXCEPT US, CND)
R123 1-216-222-00 RES-CHIP 1K 2% 1/8W
(US, CND)
R123 1-260-008-11 CARBON MELF 1K 2% 1/8W
(EXCEPT US, CND)
R124 1-216-222-00 RES-CHIP 1K 2% 1/8W
(US, CND)
R124 1-260-008-11 CARBON MELF 1K 2% 1/8W
(EXCEPT US, CND)
R125 1-216-238-00 RES-CHIP 47K 2% 1/8W
(US, CND)
R125 1-260-016-11 CARBON MELF 47K 2% 1/8W
(EXCEPT US, CND)
R126 1-216-222-00 RES-CHIP 1K 2% 1/8W
(US, CND)
R126 1-260-008-11 CARBON MELF 1K 2% 1/8W
(EXCEPT US, CND)
R127 1-216-222-00 RES-CHIP 1K 2% 1/8W
(US, CND)
R127 1-260-008-11 CARBON MELF 1K 2% 1/8W
(EXCEPT US, CND)
R128 1-216-222-00 RES-CHIP 1K 2% 1/8W
(US, CND)
R128 1-260-008-11 CARBON MELF 1K 2% 1/8W
(EXCEPT US, CND)
R129 1-208-565-41 RES-CHIP 39K 2% 1/8W
(US, CND)
R129 1-260-015-11 CARBON MELF 39K 2% 1/8W
(EXCEPT US, CND)
R130 1-208-561-11 RES-CHIP 27K 2% 1/8W
(US, CND)
R130 1-260-013-11 CARBON MELF 27K 2% 1/8W
(EXCEPT US, CND)
R131 1-208-516-41 RES-CHIP 18K 2% 1/8W
(US, CND)
R131 1-260-011-11 CARBON MELF 18K 2% 1/8W
(EXCEPT US, CND)
R132 1-208-810-11 METAL CHIP 15K 0.5% 1/10W
(US, CND)
R132 1-260-010-11 CARBON MELF 15K 2% 1/8W
(EXCEPT US, CND)
R133 1-208-810-11 METAL CHIP 15K 0.5% 1/10W
(US, CND)
R133 1-260-010-11 CARBON MELF 15K 2% 1/8W
(EXCEPT US, CND)
R134 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
(US, CND)
R134 1-260-004-11 CARBON MELF 4.7K 2% 1/8W
(EXCEPT US, CND)
R135 1-216-222-00 RES-CHIP 1K 2% 1/8W
(US, CND)
R135 1-260-008-11 CARBON MELF 1K 2% 1/8W
(EXCEPT US, CND)
R136 1-216-238-00 RES-CHIP 47K 2% 1/8W
(US, CND)
R136 1-260-016-11 CARBON MELF 47K 2% 1/8W
(EXCEPT US, CND)
R147 1-216-238-00 RES-CHIP 47K 2% 1/8W
(US, CND)
R147 1-260-016-11 CARBON MELF 47K 2% 1/8W
(EXCEPT US, CND)
R148 1-216-238-00 RES-CHIP 47K 2% 1/8W
(US, CND)
R148 1-260-016-11 CARBON MELF 47K 2% 1/8W
(EXCEPT US, CND)
R167 1-216-238-00 RES-CHIP 47K 2% 1/8W
(US, CND)
R167 1-260-016-11 CARBON MELF 47K 2% 1/8W
(EXCEPT US, CND)
R168 1-216-238-00 RES-CHIP 47K 2% 1/8W
(US, CND)
