Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
157
STR-DA5000ES
REG
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
IC934 8-759-832-29 IC NJM4580M-(TE2)
IC935 8-759-832-29 IC NJM4580M-(TE2) (US, CND)
IC936 8-759-832-29 IC NJM4580M-(TE2) (US, CND)
IC937 8-759-832-29 IC NJM4580M-(TE2) (US, CND)
IC940 8-759-524-50 IC TC74VHC541FT (EL)
IC941 8-759-524-50 IC TC74VHC541FT (EL) (US, CND)
IC2801 6-704-131-01 IC DSD1608PAHR (US, CND)
IC4001 8-759-473-41 IC BA10T
IC4002 8-759-604-50 IC M5F7910L
< SHORT >
JW901 1-216-295-00 SHORT CHIP 0
JW902 1-216-295-00 SHORT CHIP 0
JW903 1-216-295-00 SHORT CHIP 0
< COIL >
L901 1-456-545-11 COIL, CHOKE 100uH
L902 1-456-545-11 COIL, CHOKE 100uH
L4001 1-409-575-11 COIL, CHOKE 1mH
L4002 1-456-520-11 COIL, CHOKE 1mH
< TRANSISTOR >
Q905 8-729-216-31 TRANSISTOR 2SA1163-G
Q906 8-729-271-31 TRANSISTOR 2SC2713-G
Q908 8-729-271-31 TRANSISTOR 2SC2713-G
Q911 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q912 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q913 6-550-363-01 TRANSISTOR 2SB1690KT146
Q914 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q959 8-729-024-91 TRANSISTOR 2SC2712-GL-TE85L
< RESISTOR >
R905 1-249-589-11 CARBON 36K 5% 1/4W
R906 1-247-807-31 CARBON 100 5% 1/4W
R907 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
0 R908 1-216-369-00 METAL OXIDE 1 5% 2W F
R909 1-216-113-00 RES-CHIP 470K 5% 1/10W
R910 1-216-073-00 RES-CHIP 1K 5% 1/10W
R911 1-216-063-00 RES-CHIP 3.9K 5% 1/10W
R912 1-216-077-00 RES-CHIP 15K 5% 1/10W
R913 1-216-049-11 RES-CHIP 1K 5% 1/10W
R914 1-216-295-00 SHORT CHIP 0
R915 1-216-025-11 RES-CHIP 100 5% 1/10W
R916 1-216-073-00 RES-CHIP 1K 5% 1/10W
R917 1-215-869-11 METAL OXIDE 1K 5% 1W
R918 1-216-025-11 RES-CHIP 100 5% 1/10W
R919 1-249-923-11 CARBON 1K 1% 1/4W
R920 1-249-923-11 CARBON 1K 1% 1/4W
R921 1-216-073-00 RES-CHIP 1K 5% 1/10W
R922 1-249-607-11 CARBON 200K 5% 1/4W
R927 1-249-960-11 CARBON 36K 1% 1/4W
R928 1-249-937-11 CARBON 3.9K 1% 1/4W
R929 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R930 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R931 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R933 1-216-025-11 RES-CHIP 100 5% 1/10W
(US, CND)
R934 1-216-025-11 RES-CHIP 100 5% 1/10W
R935 1-216-025-11 RES-CHIP 100 5% 1/10W
(US, CND)
R936 1-216-025-11 RES-CHIP 100 5% 1/10W
(US, CND)
R937 1-216-025-11 RES-CHIP 100 5% 1/10W
R938 1-216-025-11 RES-CHIP 100 5% 1/10W
R939 1-216-025-11 RES-CHIP 100 5% 1/10W
R940 1-216-025-11 RES-CHIP 100 5% 1/10W
R941 1-216-025-11 RES-CHIP 100 5% 1/10W
(US, CND)
R942 1-216-025-11 RES-CHIP 100 5% 1/10W
(US, CND)
R943 1-216-025-11 RES-CHIP 100 5% 1/10W
(US, CND)
R944 1-216-025-11 RES-CHIP 100 5% 1/10W
R945 1-216-025-11 RES-CHIP 100 5% 1/10W
(US, CND)
R946 1-216-025-11 RES-CHIP 100 5% 1/10W
(US, CND)
R947 1-216-025-11 RES-CHIP 100 5% 1/10W
(US, CND)
R948 1-216-025-11 RES-CHIP 100 5% 1/10W
(US, CND)
R949 1-216-025-11 RES-CHIP 100 5% 1/10W
R950 1-216-025-11 RES-CHIP 100 5% 1/10W
(US, CND)
R951 1-216-025-11 RES-CHIP 100 5% 1/10W
R952 1-216-025-11 RES-CHIP 100 5% 1/10W
R953 1-216-025-11 RES-CHIP 100 5% 1/10W
R954 1-216-033-00 RES-CHIP 220 5% 1/10W
R955 1-216-001-00 RES-CHIP 10 5% 1/10W
R956 1-216-049-11 RES-CHIP 1K 5% 1/10W
R960 1-216-208-00 RES-CHIP 2.7K 2% 1/8W
(US, CND)
R960 1-260-001-11 CARBON MELF 2.7K 2% 1/8W
(EXCEPT US, CND)
R961 1-216-661-11 METAL CHIP 2.7K 0.5% 1/10W
(US, CND)
R962 1-216-661-11 METAL CHIP 2.7K 0.5% 1/10W
(US, CND)
R963 1-216-661-11 METAL CHIP 2.7K 0.5% 1/10W
(US, CND)
R964 1-216-661-11 METAL CHIP 2.7K 0.5% 1/10W
(US, CND)
R965 1-216-661-11 METAL CHIP 2.7K 0.5% 1/10W
(US, CND)
R966 1-216-661-11 METAL CHIP 2.7K 0.5% 1/10W
(US, CND)
R967 1-216-661-11 METAL CHIP 2.7K 0.5% 1/10W
(US, CND)
R968 1-208-506-11 RES-CHIP 6.8K 2% 1/8W
(US, CND)
R968 1-249-427-11 CARBON MELF 6.8K 2% 1/8W
(EXCEPT US, CND)
R969 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
(US, CND)
R970 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
(US, CND)
R971 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
(US, CND)
R972 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
(US, CND)
