Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
159
STR-DA5000ES
S-VIDEO SP TM (A) SP TM (B) SP TM (C)
C723 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C724 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C725 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C726 1-119-824-11 ELECT 10uF 20% 50V
C731 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C732 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C733 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C734 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C735 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C736 1-119-824-11 ELECT 10uF 20% 50V
C737 1-128-830-11 ELECT 47uF 20% 10V
C738 1-128-830-11 ELECT 47uF 20% 10V
C739 1-128-830-11 ELECT 47uF 20% 10V
C740 1-128-830-11 ELECT 47uF 20% 10V
C741 1-119-824-11 ELECT 10uF 20% 50V
C742 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C743 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C744 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C745 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C746 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C747 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C748 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
CNP742 1-779-977-11 PIN, CONNECTOR 6P
CNS741 1-784-778-11 CONNECTOR, FFC 17P
< DIODE >
D741 8-719-988-61 DIODE 1SS355TE-17
D742 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC701 8-759-536-24 IC NJM-2296M-TE2
IC702 6-700-050-01 IC NJM2596M (TE2)
< TERAMINAL/JACK >
J701 1-779-800-11 TERMINAL, S (MONITOR OUT S2 VIDEO)
J702 1-779-801-11 CONNECTOR (ROUND TYPE)
(TV/SAT S2 VIDEO IN, DVD S2 VIDEO IN)
J703 1-779-801-11 CONNECTOR (ROUND TYPE)
(VIDEO2 S2 VIDEO OUT/S2 VIDEO IN)
J704 1-779-801-11 CONNECTOR (ROUND TYPE)
(VIDEO1 S2 VIDEO OUT/S2 VIDEO IN)
< FERRITE BEAD >
L741 1-500-425-11 FERRITE, EMI (SMD) (3216)
L742 1-500-425-11 FERRITE, EMI (SMD) (3216)
L743 1-500-425-11 FERRITE, EMI (SMD) (3216)
L744 1-500-425-11 FERRITE, EMI (SMD) (3216)
< RESISTOR >
R701 1-216-022-00 RES-CHIP 75 5% 1/10W
R702 1-216-097-11 RES-CHIP 100K 5% 1/10W
R703 1-216-022-00 RES-CHIP 75 5% 1/10W
R704 1-216-049-11 RES-CHIP 1K 5% 1/10W
R705 1-216-295-00 SHORT CHIP 0
R711 1-216-022-00 RES-CHIP 75 5% 1/10W
R712 1-216-022-00 RES-CHIP 75 5% 1/10W
R713 1-216-022-00 RES-CHIP 75 5% 1/10W
R714 1-216-022-00 RES-CHIP 75 5% 1/10W
R715 1-216-295-00 SHORT CHIP 0
R721 1-216-022-00 RES-CHIP 75 5% 1/10W
R722 1-216-097-11 RES-CHIP 100K 5% 1/10W
R723 1-216-022-00 RES-CHIP 75 5% 1/10W
R724 1-216-022-00 RES-CHIP 75 5% 1/10W
R725 1-216-022-00 RES-CHIP 75 5% 1/10W
R726 1-216-295-00 SHORT CHIP 0
R731 1-216-022-00 RES-CHIP 75 5% 1/10W
R732 1-216-097-11 RES-CHIP 100K 5% 1/10W
R733 1-216-022-00 RES-CHIP 75 5% 1/10W
R734 1-216-022-00 RES-CHIP 75 5% 1/10W
R735 1-216-022-00 RES-CHIP 75 5% 1/10W
R736 1-216-295-00 SHORT CHIP 0
R737 1-216-083-00 RES-CHIP 27K 5% 1/10W
R738 1-216-089-11 RES-CHIP 47K 5% 1/10W
R740 1-216-022-00 RES-CHIP 75 5% 1/10W
R741 1-216-022-00 RES-CHIP 75 5% 1/10W
R742 1-216-022-00 RES-CHIP 75 5% 1/10W
R743 1-216-097-11 RES-CHIP 100K 5% 1/10W
R744 1-216-097-11 RES-CHIP 100K 5% 1/10W
R745 1-216-097-11 RES-CHIP 100K 5% 1/10W
R746 1-216-097-11 RES-CHIP 100K 5% 1/10W
R747 1-216-097-11 RES-CHIP 100K 5% 1/10W
R748 1-216-295-00 SHORT CHIP 0
R749 1-216-295-00 SHORT CHIP 0
R750 1-216-022-00 RES-CHIP 75 5% 1/10W
************************************************************
1-860-490-11 SP TM (A) BOARD
***************
< CAPACITOR >
CC004 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC005 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC011 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC012 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC018 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC019 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC025 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC026 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
1-860-491-11 SP TM (B) BOARD
***************
< CAPACITOR >
CC051 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC052 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
1-860-492-11 SP TM (C) BOARD
***************
< CAPACITOR >
CC055 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
CC056 1-100-156-91 CERAMIC CHIP 680PF 5% 100V
************************************************************
