Sony STR-DA5000ES - Page 38

STR-DA5000ES
3838
• Waveforms
– DIGITAL Board –
1 IC2201 qs (MCLK2)
2 IC2121 ws (XIN)
3 IC2125 3 (A2)
4 IC2251 <zc. (MCLK2)
5 IC2601 tk (XO)
6 IC2701 qh (XOUT)
– D-AMP Board –
qa IC1471 4 (Y)
qs IC1401 wk (XFSOIN)
qd IC1401 yf (XFSIIN)
qf IC1401 uj (XFSOOUT)
qg IC1800 ws (XO)
– VIDEO Board –
wa IC3701 qk (YOUT) (NTSC color bar mode)
ws IC3701 ql (UOUT) (NTSC color bar mode)
wd IC3701 w; (VOUT) (NTSC color bar mode)
wf IC3701 wh (XNTSC)
wg IC3701 wk (X443/358)
wh IC3701 es (CIN) (NTSC color bar mode)
wj IC3701 ef (CVBS/Y IN)
(NTSC color bar mode)
wk IC3451 4 (VOUT1)
(NTSC color bar mode)
wl IC3431 qd (V1.IN) (NTSC color bar mode)
e; IC3651 qf (XCOM) (NTSC color bar mode)
ea IC3601 7 (ACO) (NTSC color bar mode)
es IC3601 9 (AYO) (NTSC color bar mode)
3.3 Vp-p
74 ns
3.4 Vp-p
82 ns
3.4 Vp-p
40.7 ns
3.4 Vp-p
74 ns
2.8 Vp-p
60.6 ns
5.0 Vp-p
137 ns
7.2 Vp-p
20.4 ns
4.5 Vp-p
20.4 ns
4.5 Vp-p
12.4 ns
4.5 Vp-p
20.4 ns
2.6 Vp-p
125 ns
1.2 Vp-p
H
1.7 Vp-p
H
1.7 Vp-p
H
0.4 Vp-p
279 ns
150 mVp-p
226 ns
1.4 Vp-p
H
1.2 Vp-p
H
1.0 Vp-p
H
1.0 Vp-p
H
1.0 Vp-p
H
0.75 Vp-p
H
1.1 Vp-p
H
