Sony STR-DA5000ES - Page 83

83
STR-DA5000ES
IC2862 CXD9725M
TRIM VOLUME
0-+24dB/
1dB STEP
TRIM VOLUME
0-+24dB/
1dB STEP
5 to 25 DECODER
&
LATCH CIRCUIT
4 to 13 DECODER
&
LATCH CIRCUIT
4 to 16 DECODER
&
LATCH CIRCUIT
24 BIT
SHIFT REGISTER
CIRCUIT
LEVEL SHIFT
CIRCUIT
5 to 25 DECODER
&
LATCH CIRCUIT
4 to 13 DECODER
&
LATCH CIRCUIT
4 to 16 DECODER
&
LATCH CIRCUIT
1VSS
2TRIM
3TRIM
4TRIM
5OUT
6VRGND
8VRIN
7NC
10CS1
9NC
11GND
12CLK
23 TRIM
22 TRIM
21 TRIM
20 OUT
19 VRGND
17 VRIN
18 NC
15 CS2
16 NC
14 LAT
13 DATA
24 VDD
MAIN
VOLUME
0- –95dB/
0.5dB STEP
MAIN
VOLUME
0- –95dB/
0.5dB STEP
– PRE-OUT Board –
IC2812, 2862, 2912, 2962 CXD9725M
TRIM VOLUME
0-+24dB/
1dB STEP
TRIM VOLUME
0-+24dB/
1dB STEP
5 to 25 DECODER
&
LATCH CIRCUIT
4 to 13 DECODER
&
LATCH CIRCUIT
4 to 16 DECODER
&
LATCH CIRCUIT
24 BIT
SHIFT REGISTER
CIRCUIT
LEVEL SHIFT
CIRCUIT
5 to 25 DECODER
&
LATCH CIRCUIT
4 to 13 DECODER
&
LATCH CIRCUIT
4 to 16 DECODER
&
LATCH CIRCUIT
1VSS
2TRIM
3TRIM
4TRIM
5OUT
6VRGND
8VRIN
7NC
10CS1
9NC
11GND
12CLK
23 TRIM
22 TRIM
21 TRIM
20 OUT
19 VRGND
17 VRIN
18 NC
15 CS2
16 NC
14 LAT
13 DATA
24 VDD
MAIN
VOLUME
0- –95dB/
0.5dB STEP
MAIN
VOLUME
0- –95dB/
0.5dB STEP
– VIDEO Board –
IC3201 ADM3222ARU-REEL
11NC
14NC
12T2IN
10 R2OUT
9 R2IN
R2
R1
8 T2OUT
7V-
6 C2-
5 C2+
4 C1-
3V+
2 C1+
VCC
1EN
T2
13T1IN
15R1OUT
16R1IN
17T1OUT
18GND
19VCC
20SD
T1
IC3311, 3731 LA7213
1
SYNC
SEP
V-SYNC
SEP
2
3
4
5
V IN
HD
VSS
VD
VDD
