CRANEX Novus e 3. Taking an Exposure
User manual 208898 21
If the roots of the front incisors are on the same
vertical plane but not within the focal trough
reposition the patient by moving the rod and bite
block backwards or forwards.
14. Close the temple supports by sliding the temple
support knob to the right (A). Make sure that
patient’s neck is stretched and straight.
Adjust the height of the forehead support until it
is level with the patient’s forehead or nasion (B).
Carefully push the forehead support in until it
touches the patient’s forehead or nasion (C).
15. Ask the patient to press their lips together and
press their tongue against the roof of their
mouth.
Close the mirror. Then ask the patient to look at
a fi xed point in the mirror and to remain still for
the duration of the exposure.
The exposure takes approximately nine
seconds.
