Installation and set-up manual 208668 7
CRANEX Novus e 2. Pre-installation requirements
• Make sure that the fi xing hardware to be used
to attach the unit to the wall and the wall itself
can withstand a continuous pull-out force of at
least 300 kg (660 lb).
• If the wall is made of thin material, you may
have to use a reinforcing plate on the rear side
of the wall to hold the fi xing hardware.
• If the wall is not strong enough to support the
unit or if you are not sure if the wall will support
the unit, use the exhibition stand.
• The place where the unit is to be installed
and the position from where the user will take
exposures must be correctly shielded from the
radiation that is generated when the unit is
operated. Since radiation safety requirements
vary from country to country and state to state
it is the responsibility of the installer to ensure
that all safety requirements are met.
• Do not install the unit in environments where
there are corrosive or explosive vapours.
• Special steps regarding EMC need to be taken
when installing the unit. For more information
refer to the EMC declaration in the User
Manual.
• The unit must be installed at least 1.85 m
(73") away from any non-medical electrical or
electromechanical equipment.
• The unit must be connected to its own
dedicated power supply:
• 100 to 120 VAC or
• 220 to 240 VAC
• Extension cables MUST NOT be used with the
unit.
