6 Installation and set-up manual 208668
2. Pre-installation requirements CRANEX Novus e
2. Pre-installation requirements
2.1 The Unit
• The unit is supplied in one box on a pallet.
The dimensions of the box with pallet are:-
Length W
idth Height
191 cm 85 cm 103 cm
76" 34" 41"
• The assembled unit weighs 120 kg (265 lb).
Make sure that the fl oor where the unit is to be
installed can support this weight.
• The unit MUST be permanently attached to
the wall. It is strongly recommended that the
base of the column is permanently attached to
the fl oor. If it is not possible, use the exhibition
stand. See section 6. The exhibition stand.
• If the area where the unit is to be installed
is subject to earthquakes, the unit MUST be
permanently attached to the wall AND the
base of the column MUST be permanently
attached to the fl oor. If the base of the column
cannot be permanently attached to the fl oor,
use the exhibition stand. Refer to section 6.
The exhibition stand.
• The fi xing hardware (not supplied) for
attaching the unit to the wall/fl oor and the
fi xing hardware (not supplied) for attaching
the optional remote exposure switch to
the wall must be the correct type for the
wall/fl oor materials. See section 2.6 Fixing
hardware and installation and setup tools
for information on fi xing hardware.
