User Manual
4.1: MAIN MENU
TOUCH SCREEN > MAIN MENU
4.1: TOUCH SCREEN > MAIN MENU
FADER SETUP
Assign DSP channels to Control Channel slots.
Use FADER SETUP to create custom Fader Layers. See section 3.2.1 for more detail.
SYSTEM
System information, HiQnet and IP addressing, selective console reset functions, and the
Event Log.
Use the system menu to reset channels, busses, patching, and the whole console. See section 11.2 for more detail.
INSERT
Setup and patching of the four available insert sends and returns.
See section 5 - Inputs & Outputs - For more information. Remember, an insert interrupts signal flow, so if an insert
is assigned to a channel, the signal must have a return path.
PREFS
Brightness settings and D.O.G.S. system (Direct Out Gain Stabiliser) On/Off.
When enabled, D.O.G.S. Adjusts the direct output level from each channel inversely to any manual change of a mic
gain control. See section 11.1 for more detail.
SOLO
Solo system settings.
Options include Highlight, Blend, and Solo Trim levels, as well as Solo In Place and Input Priority On/O. See
section 8.4 for more information.
