SoundCraft Si EXPRESSION User Manual

User Manual
7.2.4: ACS EQUALISER SECTION
DSP ELEMENTS > ACS > EQUALISER
7.2.3: DSP ELEMENTS > ACS > EQUALISER
LO MID Q
Adjust the Q of the LO MID Filter
Q is ‘magnification’ at resonance, and is inversely proportional to bandwidth. For an equaliser it is useful to think
of it simply as a bandwidth control (the width of the ‘bell’ in the case of a bell-shaped filter). That is, the higher
the Q, the lower the bandwidth - or the more ‘focussed’ the filter. Bandwidth (in octaves) is shown on the Touch
Screen with the Function Focus feature.
LF FREQ
Adjust the centre frequency of the LF shelving lter.
The filter will boost or cut the signal at this frequency by the amount set by LF Level. The cut-o frequency will be
higher, according to the filter slope.
LF Level
Adjust the boost/attenuation of the LF shelving lter.
EQ On/Off
Switch the EQ process for this channel On and Off.
Pressing and holding the key will activate Interrogate mode for this function (see Mix Features 8.3).

SoundCraft Si EXPRESSION Specifications

General

Built-in Effects	Yes
USB Interface	Yes
MIDI I/O	Yes
Faders Type	Motorized
Phantom Power	Yes
Type	Digital
Network Connectivity	Ethernet
EQ Bands	4-band Parametric
Computer Connectivity	USB
Weight	22 lbs
Dimensions	635 x 160 x 536mm
