SPEKTRUM DX7 • HELICOPTER PROGRAMMING GUIDE SPEKTRUM DX7 • HELICOPTER PROGRAMMING GUIDE
Programmable Mixing 1–3 (continued)
[PROG.MIX1]
THRO≥ THRO ON
◊RATE: 0%
0%
SW:ON
OFFSET: 0
Press to adjust mix value
Press to enter PROG MIX
Press to enter
Function Mode
Press to return
value to default
Press to highlight RATE
Assigning Mixing Values
Press the DowN and SELECT keys simultaneously to access the Function Mode.
In Function Mode, use the UP or DowN key to select the desired PROG. MIX screen (1–3).
Press the SELECT key to highlight RATE.
Using the stick or switch that is assigned to the master channel, move that stick or switch in the desired
direction that you wish to adjust the mix value.
Press the INCREASE or DECREASE key to adjust the mix value.
Note: If a switch is assigned to the mix, that switch must be turned on to allow mixing values to
be changed.
Moving the stick or switch in the opposite direction will allow the mix value to be adjusted in the
opposite direction.
Programmable Mixing 1–3 (continued)
[PROG.MIX1]
THRO≥ THRO ON
◊
RATE: 0%
0%
SW:ON
OFFSET: 0
Press to adjust OFFSET value
Press to enter PROG MIX
Press to enter
Function Mode
Press to return
value to default
Press to
highlight OFFSET
Assigning an Offset
Press the DowN and SELECT keys simultaneously to access the Function Mode.
In Function Mode, use the UP or DowN key to select the desired PROG. MIX screen (1–3).
Press the SELECT key to highlight OFFSET.
Move the master channel’s stick to the desired offset position and press the CLEAR key to store that
offset value. The stored offset value will appear onscreen.
To change the offset value, simply move the master channel’s stick to the desired position and press
the CLEAR button.
To Next Page
