Installation and Reference Manual
Platform Overview
Installation and Reference Manual v3.2/0410/6 9
The PCS 100 is an IP Phone presented as a conventional business telephone. It provides caller ID, a
dedicated Busy Lamp Field together with pre programmed buttons for simple and easy access to system
features.
• Standard 12 button telephony functionality
• Display of number/name
• 64 x 128 Context Sensitive LCD Display
• 8 Dynamic, Context Sensitive Keys
• Headset connection.
• Powered via the LAN or optional STEPS power
supply
• Fully integrated with system database for viewing
and speed dialling users, departments, contacts
and favourites
• 2 Port QOS switch, single cable to desk.
• Can be wall mounted
• Enhanced volume and speech quality of incoming calls with Automatic Gain Control (AGC).
• Can be partnered with PCS 60 or PCS 50
The PCS 520 is an analogue handset providing the following features:
• Standard 12 button telephone keypad
• 3 line LCD display with contrast settings
• Display of Calling Line Number/Name & Called Line Name
• Dual message waiting/DND indicator
• Visual ringing indicator
• 10 pre-programmed keys
• 10 user definable keys
• Internal directory (100 names/numbers)
• Missed call/Clear/Dial/Pause/Recall/Redial/Speaker/Volume
/Mute keys
• Voicemail guide on handset
• Desktop paging
• Auto Answer
• Headset port
• Powered via the line port
• Can be partnered with PCS 60 or PCS 50
