Splicecom Maximiser - Page 28

Installation and Reference Manual
Installing a System
22
Installation and Reference Manual v3.2/0410/6
5108 Call Server – Front and Rear view
Please note that the front view diagram is incorrect, the first LED is the LINK LED and the second is the
DISK drive LED.
4100 Call Server – Front and Rear view
Integral LAN Switch with 8 x 10/100 Mbps Ethernet ports
LED status lights
SpliceCom LED
Power socket
Power socket for
Power over Ethernet PSU
10/100 Mbps
Ethernet LAN port
(for future use)
4 ISDN BRI
1 ISDN PRI
Input Triggers
Relay sockets
IP WAN Interface
Integral LAN Switch with 4 x
10/100 Mbps Ethernet ports
LED status lights
4 x analogue Phone ports
Power socket
Input Trigger
Relay socket
2 x ISDN BRI
LAN Link
