Splicecom Maximiser - Page 46

Installation and Reference Manual
System Operation
40 Installation and Reference Manual v3.2/0410/6
5330 Front View
5315 Front View
5315/30 Rear View
4300 Front and Rear View
Power
Socket
PCMCIA
Card Slot
15 or 30 analogue Phone Sockets
LAN port
30 analogue Phone Sockets
Integral LAN Switch with 4 x
10/100 Mbps Ethernet ports
LAN Link
USB Socket
15 analogue
Phone Sockets
LAN Link
USB Socket
Integral LAN Switch with 4 x
10/100 Mbps Ethernet ports
Power socket
