Installation and Reference Manual
System Operation
Installation and Reference Manual v3.2/0410/6 53
When using Telnet to, for example, upgrade the phone or change its IP Address. The phone’s password
is entered to authorise these changes. By default this is set to 7388 but this password can be changed as
follows:
1 In Manager, from the Navigation pane, select Phones
2 Select the module that the phone is connected to, eg Call Server
3 The MAC address of the unit will identify the specific phone required
4 Select the phone required
5 In the Password field enter the alpha-numeric characters required
6 Select Update or Apply to save the changes.
To determine the IP address of a PCS 570/560 select the Favourites button , then Settings and then
Phone Information (alternatively press the key at the bottom right hand side and then select Phone
Information). The IP address will be displayed at the top of the screen.
To determine the IP address of the PCS 580 press the Settings icon five times. The IP address will be
displayed at the top of the Phone Information screen.
A list of the IP addresses for each
PCS 570/560/580 can be viewed in
Manager by selecting Utilities and
then IP Addresses.
When connecting a PCS 560/570/580 to the system for the first time a DHCP server is required to give the
PCS an IP address. This address can be viewed as described above. However once connected the
PCS 560/570/580 can be given a static address as follows:
1 Within the Command prompt enter
telnet <ip address of PCS 570/560> eg telnet 192.168.0.250
2 You will be prompted for a Username, enter
diag
3 You will be prompted for the password for this phone. By default this is
7388
. (Please refer to the
Setting the Password section from page 53 for further details.)
4 Wait for a # to appear to confirm a connection has been made to the PCS
5 Enter
setnet
