10
4.1 HOME SCREEN SETTINGS
The home screen at the top and side bars will always be visible and accessible.
Setpoint: Displays the congurable mode in the applicaon you are set in.
Nozzle status: Displays the current nozzle spray status as a percentage of the maximum ow rate.
Atomizing air status: Atomizing Air Status and spray status are read-only representaons of the current status. Adjust atomizing
air in sengs, and toggle the spray status by using the run or trigger buons.
Spray status: Shows whether the nozzle is currently spraying or not.
Clean/Purge: Access or trigger the clean and purge cycle sengs.
STANDBY/RUN
Using this Toggle buon, you can swap between Run and Standby
states.
•
Run: The system will spray if it is triggered.
•
Standby: The system will stop spraying and will not react to a
new trigger signal.
If the system is busy spraying, it will nish the “follower” for the air
output to cleanly stop spraying.
TRIGGER
The trigger buon is only shown if the trigger source has been set to “Buon on home screen” in “Trigger sengs”.
Depending on your sengs, you will have:
•
Fixed spray mode, Momentary buon (single shot mode): starts a spray when clicked.
•
Variable spray mode, Toggle buon: starts & stops a spray when clicked.
4.2 PURGE AND CLEAN SETTINGS
The Purge and Clean cycles can be toggled on or o with their labeled On/O indicators at the boom of the screen. A
blue indicator with the dot on the right-hand side shows the currently selected and acve cycle.
PURGE
The purge cycle is used to empty the uid lines of liquid, or as an addional way to drain a tank or pressure pot.
The purge cycle automacally sets the nozzle duty cycle to 100% (fully open) and requires the operator to manually
turn the cycle on or o using the labeled indicator. The cycle will connue unl it is manually turned o. The other
values are not editable while the purge cycle is acve.
CLEAN
The clean cycle is commonly used to clear a nozzle that appears to
be clogged and requires the operator to set three editable values.
These values include:
•
Clean Duty Cycle — Set between 1–100%
•
Max Cycle Speed — Set between 60–5,000 cycles/minute
•
Clean Time — Set between 1–250 seconds
1750+ Home Screen
SECTION 4
1750+ HOME SCREEN
Purge and Clean sengs screen
