SECTION 3
1750+ OVERVIEW
The AutoJet
®
1750+ Spray Control System featuring an HMI Touch Screen Display is a self-contained, electronic/
pneumac panel that provides control of various aspects of a spray system. These systems come in a variety of design
conguraons depending on the requirements of your spray applicaon, therefore, you may or may not have all the
features described in this owner’s manual.
3.1 FEATURES
The Spraying Systems Co.
®
AutoJet 1750+ Spray Control System is a self-contained unit that can provide you with
precise liquid delivery and spray nozzle control in an aordable easy to use turn-key spray system. The system comes in
a variety of designs and conguraons based on the type of spray nozzle used in your applicaon.
The system can be used with water, oils, lubricants, inks, stains, water-based solvents, and non-abrasive slurries. The
system is designed to spray most non-ammable or non-volale materials. Liquids and materials that ow with
viscosies below 1000 cP at 68°F (20°C) can be sprayed with the correct spray nozzle and controlled with this unique
spray system soluon.
SYSTEM USAGE
•
The AutoJet 1750+ Spray Control System is designed to run connuously or intermiently.
•
The AutoJet 1750+ Spray Control System features a high-quality HMI touchscreen interface.
— The user can set and control dierent spray ming such as; spray period, start delay, and stop delay mes.
•
The controller is designed to run both electric and air actuated spray nozzles.
— Can drive Spraying Systems Co. electric-actuated spray nozzles (3.6 amps. max.) with Pulse Width Modulaon
(PWM). Specically, the PulsaJet® spray nozzle line and the AA250AUH Electric spray nozzles can be used.
— PWM (Pulse Width Modulaon) is a technique used to control ow rate by rapidly pulsing the nozzle on and o
and uses a duty cycle within the spray me. Duty Cycle (DC) is the percent of me of the total cycle me the
nozzle is spraying. If the nozzle is spraying 50% of the me, the DC is 50% thus the ow is ½ that of the nozzle
being fully open.
3.2 SPECIFICATIONS
•
4.3” HMI Touch Screen display unit featuring custom programming.
•
UL Type 1, stainless steel control panel.
•
Stainless steel enclosure, wash-down with door closed, not explosion proof (Non-Ex).
•
Power ON/OFF switch with Power on LED indicator light.
•
Power input 110-230VAC, 50/60, 1 ph., 2.2A (Plug into a GFCI outlet).
•
Global compability Mul-voltage power cords available
•
Power cord, 6 . (2m) length.
•
Output 24 Vdc
•
3.6 amps dedicated to electric spray nozzles and sensors
•
Wireless access point.
•
Inputs for 1 analog input, 3 digital inputs and 3 digital outputs.
•
Includes digital output for air atomizing solenoids.
•
Oers dual digital inputs for conveyor interlock type trigger.
•
Features local and remote triggering opons.
•
Independent ming ranges for spray and delay adjustable from 0 to 20,000 seconds.
•
Delays for atomizing air (ancipator and follower mes) can be set 0 to 10 seconds.
