Spraying Systems AUTOJET 1750+ - Short Distance Laser Sensor; Long Distance Laser Sensor; Fault Output Signal

40
12.10 LASER SENSOR (SHORT)
For accurate short distance sensing of objects (thin, shiny, dark, clear, mul-faceted)
SPECIFICATIONS:
Laser sensor – with cable, connector, and bracket.
•
Kit number: 040TS04000135W0
•
NPN – NO + NC
•
1.0” – 3.5” [25mm – 90mm] sensing range (1.5mm – 3mm deviaon range).
•
Working temperature range = 10°F to 122°F [-10°C to 50°C]
•
IP69K, NEMA 4X; CE rated
• Mounng bracket, accurate short sensing distances of 25 to 90 mm, std. detectable deviaon 1.5-
3.0mm, NPN/PNP open collector, 24Vdc, M12 4 pin male connecon, 5m cable.
12.11 LASER SENSOR (LONG)
For accurate long-distance sensing of objects (shiny, dark, clear, mul-faceted)
SPECIFICATIONS:
Laser sensor – with cable, connector, and bracket.
•
Kit number: 040TS04000087W0
•
NPN – NO + NC
•
1.38” – 19.69” [35mm – 500mm] sensing range (9mm – 50mm deviaon range).
•
Working temperature range = 10°F to 122°F [-10°C to 50°C]
•
IP69K, NEMA 4X; CE rated
•
5m cable, and mounng bracket, 24Vdc, NPN. IP68/ IP69K.
12.12 FAULT OUTPUT SIGNAL
The SCS Series spray control panels oer a feature to signal your system when a fault has occurred in the operaon of
the spray control panel (for example a level sensor going low or a short in one of the nozzle cables). To use this fea-
ture, you need to have our oponal splier cable kit.
Wire the fault output to any 24VDC buzzer, light, or PLC. You will need the splier and the extra cable shown below.
•
Kit 040TS04000054W0 includes both parts.
This end goes in the Main connector on the 1750+ panel. The black and the white wires from the ying leads cable
get wired to your PLC or light or buzzer, snip the blue and brown wires, they are not used. Fault cable pinout below:
If any electric nozzles are used, they get hooked up to the open M12 connector on the wye connector.
•
Panel connecon: Main
•
Cable: M12 4 pin (M) x Flying Leads - 16.4 . [5 m] (Connects to one connector on splier), ying leads (Part
number: LE00M12M5M)

The ying leads from cable of the kit are to be connected to the customer’s PLC or warning signal light,
+24VDC. (black and white wires)
•
Adapter: Splier – M12 (M) x 2 M12 (F) - 3 . [1 m] whip
cord length (Part number: LE00M12WYE1M)
•
Open connector on splier

Connect PulsaJet cable; AA250 cable; or extension
cable to this connecon.
