ST G3-PLC - Page 28

MAC menu UM1811
28/52 DocID026814 Rev 1
macCSMAFairnessLimit
The channel access fairness limit. Specifies how many failed back-off
attempts, back-off exponent is set to minBE
macTMRTTL
Maximum time to live of tone map parameters entry in the neighbor
table in seconds
macNeighbourTableEntryTTL Maximum time to live for an entry in the neighbor table in seconds
macRCCoord
Route cost to coordinator to be used in the beacon payload as
RC_COORD
macToneMask Defines the tone mask to use during symbol formation.
macBeaconRandomizationWindowLengh Duration time in seconds for the beacon randomization.
macA This parameter controls the adaptive CW linear decrease
macK Rate adaptation factor for the channel access fairness limit
macMinCWAttempts The number of consecutive attempts while using minimum CW
macCENELECLegacyMode This read only attribute indicates the capability of the node
macFCCLegacyMode This read only attribute indicates the capability of the device
Table 6. MAC G.9903 information base attributes (continued)
Standard G.9903 attributes
Table 7. MAC ST implementation defined information base attributes
ST implementation defined attributes
aExtendedAddress EUI-64 address to be used
SNRdBLOW The low threshold for the SNR
SNRdBHIGH The high threshold for the SNR
macCoordinatorType MAC coordinator type definition: 0 device, 1 coordinator
macTrxStateNotCorrect
The counter of discarded frames due to an invalid state of the real-time
engine
macPsduToLong The counter of discarded frames due to a too long PDU
macInvalidFrameType
The counter of discarded frames due to an invalid frame type field
detected
macInvalidFrameVersion
The counter of discarded frames due to an invalid frame version field
detected
macInvalidDAM
The counter of discarded frames due to an invalid destination address
mode detected
macInvalidSAM
The counter of discarded frames due to an invalid source address mode
detected
macInvalidPANId The counter of discarded frames due to an invalid PANId detected
macInvalidShortAddr
The counter of discarded frames due to an invalid short address
detected
macInvalidExtAddr
The counter of discarded frames due to an invalid extended address
detected
macInvalidBeacon The counter of discarded frames due to an invalid beacon detected
