DocID026814 Rev 1 29/52
UM1811 MAC menu
52
macInvalidDataCmd The counter of discarded frames due to an invalid command detected
macInternalStateNotCorrect
The counter of discarded frames due to an invalid state of MAC when
receiving a PD-DATA.indication
macFrameDiscarded
The counter of discarded frames for other reasons not represented by
other errors
macAckTrxStateNotCorrect
The counter of discarded ACK frames for the PHY state not correct
(PHY In TX)
macAckNotCorrect The counter of discarded ACK frames for wrong FCH received
macAckIntStateNotCorrect The counter of discarded ACK frames for an invalid state of the MAC
macAckCrcNotExpected The counter of discarded ACK frames for invalid CRC expected
macAckDiscarded The counter of total discarded ACK frames
macCSMASeed Initial seed of the CSMA/CA procedure
macInvalidFramePending
The counter of discarded frames due to an invalid frame pending field
detected
macInvalidPIC The counter of discarded frames due to an invalid PIC field detected
SNRdBROBO The tone map algorithm threshold for the robust mode
SNRdBDBPSK The tone map algorithm threshold for DBPSK modulation
SNRdBDQPSK The tone map algorithm threshold for DQPSK modulation
SNRdBD8PSK The tone map algorithm threshold for D8PSK modulation
macRXBeaconReceivedFromLastScan The number of received beacons from the start of the last scan
macModulationControl
The field mask to control the modulation used by the MAC layer where:
Bit [0 … 3]: defines the modulation to be used for the data dtransmission
(0: ROBO, 1: DBPSK or BPSK, 2: DQPSK or QPSK, 3: D8PSK or 8PSK,
F use neighbor table)
Bit [4 ... 7]: defines the modulation scheme to be asked in the tone map
response (0: ROBO, 1: DBPSK or BPSK, 2: DQPSK or QPSK,
3: D8PSK or 8PSK, F use the internal algorithm)
Bit 8: if 1 forces the differential data transmission
Bit 9: if 1 forces the differential modulation in the tone map response
macOptionalFeatures
The field mask to control the optional features provided by the MAC
layer where:
Bit 0: if 1 it enables the TMR bit in the tone map response
Bit 1: if 1 it enables the encryption of the tone map response
Table 7. MAC ST implementation defined information base attributes (continued)
ST implementation defined attributes
