Setup ST500 Tach-Timer
© Stack Limited
40
Standard feature on ST500M. Optional on other
models.
Use the rotary control as explained above to
alter the distance from the beacon to the point where you want the second
split (S2).
Optional feature on all models.
Selects the shift light mode.
Disabled The shift lights do not illuminate at any engine speed.
Single All four shift lights illuminate together when the engine
speed reaches the set point for Shift light 4 as explained
below.
If your Tach-Timer does not include the sequential programming op-
tion, only the ‘Single’ setting will be available. If your Tach–Timer in-
cludes an external shift light, this will perform identically to the right-
hand shift light (except that it does not flash when you use the ‘Seq-blink’
option).
Sequential The shift lights illuminate singly in sequence from left to
right as the engine speed reaches each set point, with all
the lights showing when the engine speed reaches the set
point for Shift light 4 (the right-hand shift light):
!""" "!"" ""!" !!!!
