ST500 Tach-Timer Setup
© Stack Limited
41
Seq-bar The shift lights illuminate in sequence, with each light
adding to those already illuminated as the engine speed
reaches each set point:
!""" !!"" !!!" !!!!
Seq-blink The shift lights illuminate in the sequence as explained
above, but they will flash together when the engine speed
reaches the set point for Shift light 4.
!""" !!"" !!!" !!!!!"
Optional feature on all models.
Shift light 1 (the left-hand light) illuminates
while you make this adjustment. Press and turn
the rotary control to adjust the set point for engine speed when Shift
light 1 illuminates. As you adjust the set point, the tachometer needle
also moves around the scale to show the setting. The Tach–Timer always
maintains the correct sequence so that the Shift lights illuminate from
left to right as the engine speed increases.
Optional feature on all models.
This function operates identically to ‘Shift 1’,
except that Shift light 2 illuminates.
