9.8.1.2 Handset with Locking Box (Optional)
Depending on the features which the bed is fitted with, the bed comes with a conventional handset
and an additional locking box. This allows electric bed functions to also be adjusted using the
handset. If for safety reasons, individual handset functions need to be locked, this is not done on
the handset itself but on a separate locking box.
x Explain the handset functions to the patient!
x The electric motors operate as long as the corresponding buttons are kept pressed.
x Adjustments are possible in both directions.
x The handset can be hung at any position on the bed with an elastic hook.
x The coiled cable provides ample flexibility and freedom of motion.
Depending on the motor fitted, the
number of keys may vary.
The following basic rule applies to the
keys:
Raise
Lower
Height Adjustment
The mattress base height can be adjusted from approx. 43 to 82 cm.
If the mattress base is tilted, it moves automatically into a horizontal position
when it reaches the highest or lowest setting.
Thigh Rest
The thigh rest can be raised to approx. 35°/39°.
(EM1 to approx. 39°, EM2 to approx. 39°, EM3 to approx. 35°)
