Item Control / Display Function
19 Display unit
Operating information and
warning message display.
20 "Lifting" button Lift the storage table.
21 "Lowering" button Lower the storage table.
22 "Horn" button Activates the horn.
23 "Lifting" button Lift the lift platform.
24 "Lowering" button Lower the lift platform.
25 Key switch
Switches control current on
and off. Removing the key
prevents the truck from being
switched on by unauthorized
personnel.
26 Emergency stop switch
Disconnects the supply cur-
rent, deactivates all electrical
functions, causing the truck to
brake automatically.
27 Travel switch
Select the required driving di-
rection and speed.
28 Right dead man switch
Apply the right drive pedal to
start up the truck.
30 Sensor switch
The right hand must be placed
in the position of the sensor
switch to control the truck to
move (eg. driving, raising, low-
ering).
31 Steering wheel
Steers the truck in the required
direction.
Overview
3
Control elements
52 5091 801 1525EN-12/2022 - 06
