Stonex S10A GNSS Receiver – User Manual 42
EAST DIRECTION
First step: incline S10 to EAST.
Tilt angle must be between 25°-35°
South: 180°. When both tilt angle
and azimuth are correct S10 starts
saving 10 point automatically. To
keep the angle as much as possible
close to 180° is strongly suggested.
A beep is heard when finished.
Tilt angle must be between 25°-35°
Find the right direction using the
compass of the bracket or azimuth:
EAST: 90°. When both tilt angle
and azimuth are correct S10 starts
saving 10 point automatically. To
keep the angle as much as possible
close to 90° is strongly suggested.
A beep is heard when finished.
SOUTH DIRECTION
Second step: incline S10 to the SOUTH direction.
