Stonex S900
+
GNSS Receiver – User Manual 41
7.2.2 TRM121
7.2.2.1 Fixed frequency
Protocol
Bandwidth (kHz)
Modulation
Radio link rate (bps)
FEC
Scramble
TRIMTALK(4800)
12.5
GMSK
4800
Off
N/A
TRIMTALK 450S
25
GMSK
9600
Off
N/A
TRIMMARK III
12.5
GMSK
9600
Off
N/A
TRIMMARK III
25
GMSK
19200
Off
N/A
PCC-GMSK
12.5
GMSK
4800
On
N/A
PCC-GMSK
25
GMSK
9600
On
N/A
PCC-4FSK
12.5
4FSK
9600
Off/On
N/A
PCC-Satel
25
4FSK
19200
Off/On
Off/On
PCC-Satel
12.5
4FSK
9600
Off/On
Off/On
PCCFST
12.5
4FSK
9600
Off/On
N/A
PCCFST_ADL
12.5
4FSK
9600
Off/On
N/A
Satel
12.5
4FSK
9600
Off/On
N/A
Satel
25
4FSK
19200
Off/On
N/A
Satel_ADL
12.5
4FSK
9600
Off/On
N/A
Satel_ADL
25
4FSK
19200
Off/On
N/A
South 9600
12.5
GMSK
9600
On
N/A
South 19200
25
GMSK
19200
On
N/A
7.2.2.2 Hopping
Protocol
Bandwidth (kHz)
Modulation
Radio link rate (bps)
900M Hopping
280
GMSK
115200
GEO FHSS
280
GMSK
115200
