Strong SRT 7015 User Manual

10
2.5 Installing the batteries
Fig.4
Remove the battery cover from the remote control and put 2x AAA size batteries inside the compartment.
The diagram inside the battery compartment shows the correct way to install the batteries.
1. Open the cover
2. Install batteries
3. Close the cover
NOTE: The batteries should not be recharged, disassembled, electrically short-circuited, be mixed or used
with other types of batteries.
2.6 Using the remote control
Fig.5
To use the remote control, point it towards the front of the digital receiver. The remote control has a range of
up to 7 metres from the receiver, if properly aligned towards the IR eye on the front panel.
The remote control will not operate if its path is blocked.
NOTE: Sunlight or very bright light might decrease the sensitivity of the remote control.
USB 5V
500 mA max.

Strong SRT 7015 Specifications

General

Flash memory	4 MB
Internal memory	64 MB
Signal source	Satellite
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Digital signal format system	DVB-S, DVB-S2
Personal Video Recorder (PVR) included	-
AC input voltage	100 – 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	- W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
AC adapter included	Yes
Ethernet LAN	No
Tuner type	Digital
Demodulation	8PSK, QPSK
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus
Frequency range	950 - 2150 MHz
Number of tuners	- tuner(s)
Channels quantity	2000 channels
Audio output channels	2.0 channels
Digital Satellite Equipment Control (DiSEqC)	1.2, 1.3
Composite video out	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio formats supported	AC3
Video formats supported	H.264, MPEG2, MPEG4

Weight and Dimensions

Depth	41 mm
Width	171 mm
Height	104 mm
Weight	260 g
