pg 33
MIDI Specifications (continued)
MIDI CCs
CC# PARAMETER RANGE ENUMERATION
0 Bank Select 0-2 (0=Bank 1, 1=Bank 2, 3=Bank 3)
11 Voice 1-3 (1=3205, 2=3005, 3=multi)
12 Time 0-127
13 Filter 0-127
14 Repeats 0-127
15 Mod 0-127
16 Mix 0-127
17 Tap Division 0-3 (0=triplet, 1=eighth, 2=dotted
eighth, 3=quarter)
27 Footswitch 0, 127 (0=release, 1-127=press)
93 Tap 0, 127 (any value)
97 Infinite 0, 127 (0=release, 1-127=hold)
100 Expression Pedal 0-127 (0=heel, 127=toe)
102 Bypass/Engage 0, 127 (0=bypass, 1-127=engage)
NOTE: All on/off parameters are implemented with 0=off and any other
value (1-127)=on� They are documented as “0” and “127” because many MIDI
controllers send out 0 and 127 for on/off switches�
NOTE: Some MIDI applications and controllers start their MIDI enumeration
with 1 instead of 0� In these setups, increment the numbers above by one�
